VIGI PS90 1024Wh Solar Controller | Remote Management and IP66 Resistant

VIGI PS90 1024Wh Solar Controller | Remote Management and IP66 Resistant

-45% New

VIGI PS90 TP-Link VIGI - is a solar controller for video surveillance systems equipped with a 1024.92Wh automotive-grade lithium battery, replaceable and designed to last over 500 cycles with residual capacity over 70%. Thanks to MPPT technology, it increases charging efficiency by up to 20% and guarantees autonomy even in difficult conditions. Intelligent auxiliary heating ensures optimal battery performance even at low temperatures, while the independent protection circuit keeps the power supply safe and stable. The system offers remote management and maintenance via the VIGI App, VIGI Cloud VMS or VIGI VMS , ensuring continuous control. With IP66 weatherproof certification, it is ideal for professional, reliable and resistant outdoor installations.

Technical data sheet


3 Year Warranty


Reference: VIGI PS90

Brand: VIGI

EAN: 1210002601009

Manufacturer Object ( [id] => 52 [name] => VIGI [description] =>

The history of VIGI dates back to the growing demand for high-quality video security solutions. With increased security awareness, people were seeking reliable solutions to monitor and safeguard their spaces. TP-Link responded to this need by introducing the VIGI brand.
VIGI products include various types of surveillance cameras, such as bullet cameras, dome cameras, PTZ cameras, and more. These cameras come with advanced features like high-definition video resolution, night vision, motion detection, push notifications, and much more. Additionally, many VIGI cameras offer the option to store videos on microSD cards or use cloud storage services.
TP-Link has earned a reputation for reliability and quality in the networking industry, and the VIGI brand has continued this tradition in the video security sector. With a constant commitment to innovation and quality, TP-Link continues to expand the VIGI product line to meet the growing security needs of the market.

[short_description] =>


The VIGI brand was launched by TP-Link as a line of advanced video surveillance products, focused on home and commercial security. This product line was designed to offer reliable, high-performance, and user-friendly video surveillance solutions to help people protect their homes, businesses, and properties.

[id_address] => [date_add] => 2024-06-11 17:20:54 [date_upd] => 2025-02-18 16:36:33 [link_rewrite] => vigi [meta_title] => [meta_keywords] => [meta_description] => [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 1 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
FIND INSTALLER


CLEARANCE SALE ×


 CLEARANCE SALE!
Take advantage of our must-see outing offers.
  Discover the promo >>

VIGI PS90 | 93.6Ah/10.95V Automotive-Grade Lithium Battery


Made VIGI

The VIGI PS90 is an advanced solar controller designed to power video surveillance systems reliably and continuously, even in harsh environmental conditions. Thanks to its replaceable and safe 1024.92Wh automotive-grade lithium battery, it guarantees long-lasting performance with over 500 usage cycles. With MPPT technology for more efficient charging, remote management via the VIGI App and VIGI Cloud VMS, and IP66 weatherproof certification, it is the ideal solution for professional installations.

Main specifications:

- Replaceable 1024.92Wh lithium battery

- MPPT charging efficiency +20%

- Remote management and maintenance via app and cloud

- IP66 protection for dust and water resistance

- Intelligent heating technology for low temperatures

Further details

Battery Capacity:
The VIGI PS90 integrates a 1024.92Wh automotive-grade lithium battery , with maximum 93.6Ah modules (31.2Ah per battery) . Thanks to the independent protection circuit and the intelligent auxiliary heating system, the battery maintains high performance even in extreme climatic conditions and guarantees over 500 use cycles with residual capacity >70% , offering long-term continuity and reliability.
Interfaces :
Equipped with a complete set of connections, it includes 3-pin connectors for the controller and modular battery, two 4-pin connectors for solar panels , a 10/100 Mbps RJ45 port for networking, and three 5.5 mm DC jacks (9–12.6V/2A and 12V/2A) for powering devices. Integrated LED indicators (SYS, LAN, PV, and BAT) facilitate real-time monitoring, while IP66 certification ensures water and dust resistance for safe outdoor installations.

Technical data sheet

BATTERY
Type Lithium
Intelligent Auxiliary Heat Yes
Battery Capacity 93.6Ah(Max),31.2Ah(For Lithium Battery)
Voltage 10.95 V
Max. Output Voltage 12.6 V
Life More than 500 cycles†
Dimension 9.4×2.9×2.8 in (240×74×72 mm) (For Lithium Battery)
Charging Condition 0°C~45°C
-30°C~45°C (With intelligent auxiliary heating)
Discharging Condition -20°C~60°C
-30°C~60°C (With intelligent auxiliary heating)
HARDWARE
Interface 1× Three-pin Female Connector For Connecting The Controller
1× Three-pin Male Connector For Connecting The Modular Battery
2× Four-pin Female Connectors For Connecting The Solar Panel
1× 10/100 Mbps RJ45
3× 5.5mm DC Power Plugs (#1, #2: 9V-12.6 VDC/2A, #3: 12 VDC/2A)
LED indicator Quantity: 6 (1× SYS Indicator, 1× LAN Indicator, 1× PV Indicator, 3× BAT Indicator)
Color: Blue
SOFTWARE FEATURES
Load Control Yes
High and Low Temperature Protection Yes
Overdischarge Protection Yes
Power Consumption Statistics Yes
Displays Real-time Load Status Yes
Battery Level Display Yes
Time Zone Selection Yes
Schedule Saving Yes
Firmware Remote Update Yes
Remote Reboot Yes
Local LAN Management Yes
Intelligent Auxiliary Heating Control -30°C~5°C
Account Management Yes
Remote Reset Yes
Remote Message Push Yes
OTHER
Certification CB, PSE (Battery)
CE, FCC, VCCI, IC, IP66
Package Contents VIGI PS90
Installation Guide
Waterproof Cable Attachments
Mounting Accessories
Extension Cable
Box Key
Box dimensions (L x W x H) 18.9×16.8×6.4 in (481*426*163 mm)
Weight Product Weight: 16.5 kg
Package Weight: 24 kg
Environment Operating Temperature: -30°C-60°C (With intelligent auxiliary heating)
Operating Humidity: 10%~90%RH, Non-condensing
