copy of ASI1201A-D - Dahua - Lettore RFID autonomo copn connessione a PC e tstiera touch e schermo LCD
Dahua Access Control - ASI1201A-D - RFID reader with PC connection, with touch keypad and LCD display - 13.56MHz / 125khz (Mifare) card format and ID EM Card - Reading distance 3-8cm - Supports access by card, code , or card + code - Connection to PC via RS-485 or TCP/IP - 1 door sensor, 1 exit button, 2 alarm inputs - 3 relays (doors, stamp, alarm) - Door waiting time alarm , intrusion, duress or sabotage alarm - 32bit processor - RS485, Wiegand protocol - Supports 30,000 cards and 150,000 events - Watchdog - IP55 protection - Wall installation - Dahua Technology.
DAHUA: LOSS LEADER×
 INCREDIBLE DISCOUNTS
on a selection of DAHUA products
 Check out the promo now >>
CLEARANCE SALE ×
 CLEARANCE SALE!
Take advantage of our must-see outing offers.
  Discover the promo >>
RFID PROXIMITY READER - FOR MIFARE 13,56MHZ 125KHZ CARDS - ID EM CARD - WITH TOUCH KEYPAD AND PC CONNECTION - IP55 - DAHUA - ASI1201A-D

| DESCRIPTION: Extremely reliable product. |
Product details

- Waterproof RFID Reader - Dahua Security
- Useful for access control with MIFARE 13.56Mhz/125khz card RFID reader, ID EM Card
- Numeric touch keyboard with blue backlighting
- Communication: TCP/IP (RJ45 10/100M), RS485, Wiegand
- Identification through RFID Cards, Code or combination
- Compatible Mifare 13.56Mhz / 125khz cards (Range 3-8cm (max.))
- 32Bit processor, 16M memory
- Door time out alarm, intrusion alarm, duress alarm and tamper alarm
- Fast card read/response times (<0.1s)
- Inputs: 1 door sensor, 1 exit button, 2 alarm inputs
- Output: 3 relays (doors, tone, alarm)
- Capacity up to 30,000 users, 150,000 events
- Watchdog Analysis Function
- User hierarchy: General, VIP, Guest, Patrol, Black list
- Power supply: 9-15DC/200mA
- Dimensions: 97mm*16mm*150mm
- Weight: 0.3Kg
- IP55 protection
- Operating temperature: -5°C~+55°C
Data sheet
| ASI1201A-D | |
| Technical Specification | |
| System | |
| Main Processor | 32 Bits |
| Memory | 16M |
| Input/Output Ports | |
| Input | Door sensor x 1, Exit button x 1, Alarm input x 1 |
| Outputs | Relay :Door lock×1 TTL: Bell×1, Alarm×2 |
| Readers | Reader x 1 |
| Card Read | |
| Read Format | 13.56MHz(Mifare)/125KHz - EM ID |
| Read Range | 3-8cm (max.) |
| Response Time | <0.1s |
| Capacity | |
| cardholders | 30,000 |
| Events | 150,000 |
| Function | |
| User Management | General, VIP, Guest, Patrol, Blacklist, Duress |
| Alarm Function | Door time out alarm, Intrusion alarm, Duress alarm, Tamper alarm |
| Period Setting. | Support 128 groups of schedules, 128 groups of periods and 128 groups of holiday periods |
| interface | |
| To PC | RJ45(10/100M) |
| To Reader | Wiegand/RS485 |
| General | |
| RTC extension | Yes |
| Voice prompts | No |
| Beep Tone | Buzzers |
| Keyboard | Sensitive touch keypad with blue backlight |
| Power Supply | 9-15DC/200mA |
| Working Environment | -5°C~+55°C |
| Working Humidity | ≤95% |
| Dimension(W×D×H) | 97mm*16mm*150mm |
| Weight | 0.3Kg |
Further details
|  | This terminal is STANDALONE . This means that it is autonomous, able to manage functions without having to integrate other devices. |
|  | 32BIT processor |
|

 | Standalone RFID reader with touch keyboard and identification via:
 - Combination - 13.56MHz format card (Mifare)
 |
|   | Communication via TCP/IP (RJ45 100M), RS485 or Wiegand26/34 |
|
 | Up to 30,000 user files , 150,000 events!!! |
|  | Smart features: - Intrusion alarm, door time out alarm, tampering alarm |
|  | Watchdog function for analyzing device anomalies |
|  | This product is covered by a 24 month guarantee. |
