Dahua XVR1B04-I: 4 Channel 1080p DVR with AI WizSense and SMD Plus

Dahua XVR1B04-I: 4 Channel 1080p DVR with AI WizSense and SMD Plus
-56% New

The XVR1B04-I is a 4-channel penta-brid digital video recorder, ideal for compact and reliable surveillance systems. Thanks to WizSense technology with AI algorithms, it offers advanced intelligent detection functions, reducing false alarms. It supports cameras up to 1080p , with HDCVI, AHD, TVI, CVBS video inputs and up to 5 2MP IP channels , with an input bandwidth of up to 20 Mbps. It integrates the SMD Plus function to distinguish people and vehicles, AI Coding H.265+ technology that reduces storage space by over 50% and smart functions such as Smart Dual Light , customizable audio and Audio over Coax . With support for a SATA disk up to 6TB , it represents an economical yet powerful solution for ensuring security in residential and commercial environments. Dahua

Technical Data Sheet

Reference: XVR1B04-I

Brand: Dahua

Manufacturer Object ( [id] => 13 [name] => Dahua [description] =>

The Asian Company, born in 2001, is famous because of the excellent quality of its product in terms of performances and potential.

The range of products made by Dahua includes not only classic CCTV systems but also more complex and articulate systems: not only video surveillance, indeed, but also access control, video intercoms, thermal cameras and much more.

The reliability, the cutting-edge technologies and the competitive prices offered by Dahua are only some of the reasons why Setik has always chosen to distribute this brand. Dahua has been for years a reference point in the international CCTV market, due to the huge investments dedicated every year to Research and Development. Numbers are clear: since 2016, Dahua has registered more than 800 patents with its own brand.

The Dahua-branded products sold by Setik Srl could eventually be delivered as OEM: this means that the items are absolutely original and made by Dahua, but characterized by a different aesthetic look reserved for the online market (generally as far as the logo and the package are regarded).

This has no effects on the warranty and on the technical specifications nor even on the possible updates and functionalities, because the products are authentic Dahua’s ones.

[short_description] =>

Videosorveglianza Dahua

Zhejiang Dahua Technology Co., Ltd. is one of the leading solution providers in video surveillance industry, with more than 13,000 employees and 35 active branches all over the world.

[id_address] => [date_add] => 2012-07-14 17:53:54 [date_upd] => 2025-06-24 15:40:21 [link_rewrite] => dahua [meta_title] => Best Dahua Products: DVR, HCVR,NVR, IPC,SD,PTZ,HDCVI, [meta_keywords] => dahua, dahuatech, dahua distribution, dahua national supplier [meta_description] => Dahua, TVCC manufacturer, IP, Analogue and SDI,HD-CVI [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 1 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
FIND INSTALLER


CLEARANCE SALE ×


 CLEARANCE SALE!
Take advantage of our must-see outing offers.
  Discover the promo >>

XVR1B04-I | WIZSENSE 4CH PENTA-BRID 1080N/720P COOPER 1U 1HDD DIGITAL VIDEO RECORDER


Dahua

The Dahua XVR1B04-I is a 4-channel penta-brid digital video recorder with support for up to 1080p, designed to ensure reliable and intelligent security. Thanks to WizSense technology with AI algorithms and SMD Plus function, it distinguishes people and vehicles, reducing false alarms. It supports HDCVI, AHD, TVI, CVBS video inputs and up to 5 2MP IP channels, with AI Coding H.265+ compression that reduces bandwidth and storage consumption. It offers smart features such as intelligent Dual Light, customizable audio, Audio over Coax and mobile alarm management. With support for SATA disks up to 6TB, it represents a compact and effective solution for residential and commercial surveillance systems.

Main specifications:

- 4 channels penta-brid up to 1080p

- AI WizSense technology with SMD Plus

- Support up to 5 IP channels (20 Mbps)

- AI Coding H.265+ for storage and bandwidth savings

- Smart Dual Light and Audio over Coax

- HDD storage up to 6TB

Further details

Number of Channels:
Supports up to 4 analog channels with the possibility of extension up to 5 IP channels , offering flexibility for small and medium sized installations.
Maximum resolution :
Compatible with cameras up to 1080p in CVI, TVI and AHD mode, ensuring clear and detailed images.
WizSense Technology:
It integrates deep learning algorithms for intelligent analysis, with a particular focus on people and vehicle recognition.
SMD (Smart Motion Detection):
The SMD Plus function reduces false alarms by filtering events caused by rain, leaves or changes in light, improving reliability.
Audio and Video:
HDCVI, AHD, TVI, CVBS and IP video inputs, AI Coding H.265+ compression, HDMI and VGA output up to 1080p, with two-way audio support.
Alarm:
Complete management of general alarms (motion, PIR, disk anomalies, network, tampering) and intelligent ones with customizable notifications and multiple links.
Disk capacity:
One SATA port with support for up to 6TB , ideal for long-term storage.
XVR1B04-I dimensions

Technical data sheet

XVR1B04-I

System

Main Processor

Industrial-grade processor

Operating System

Embedded Linux

Operating Interface

Web, Local GUI

SMD Plus

SMD Plus by Recorder

4 channels: Secondary filtering for human and vehicle, reducing false alarms caused by leaves, rain and lighting condition change

Audio and Video

Analog Camera Input

4 BNC ports, supports HDCVI/AHD/TVI/CVBS auto-detect

Camera Input

1. CVI: 1080p@25/30fps; 720p@50/60fps; 720p@25/30fps.
2. TVI: 1080p@25/30fps; 720p@25/30fps.
3.AHD: 1080p@25/30fps; 720p@25/30fps.

IP Camera Input

Up to 5 channels of IPC access
1 IP channels by default + 4 channels (analog channels are converted to IP channels)
Incoming bandwidth: 32 Mbps, recording bandwidth: 32 Mbps and outgoing bandwidth: 20 Mbps
*After IP extension is enabled, the AI Function (SMD) will be disabled.

Encoding Capability

Main stream: 1080N/720p/960H/D1/CIF@(1 fps–25/30 fps)
Sub stream: CIF@(1 fps–15 fps)

Dual-stream

197.0 mm × 203.1 mm × 41.5 mm (7.76" × 8.00" × 1.63") (W × D × H)

Packaging Dimensions

332.0 mm × 240.0 mm × 64.0 mm (13.07" × 9.45" × 2.52") (W × D × H)

Operating Temperature

–10 °C to +55 °C (14 °F to +131 °F)

Storage Temperature

–20 °C to +60 °C (–4 °F to +140 °F)

Operating Humidity

10%–93% (RH), non-condensing

Installation

Desktop

Certifications

CE-LVD: IEC 62368-1:2014
CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014 CE-LVD: EN 62368-1:2014
FCC: 47 CFR Part 15, Subpart B

All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
