N236-16P NVR 36 Channels 16 PoE H.265 4K 8MP Dual HDD ONVIF - Imou

N236-16P NVR 36 Channels 16 PoE H.265 4K 8MP Dual HDD ONVIF - Imou

 
HDD space calculation
New

NVR-N236-16P-8A0E-P-IMOU - The N236-16P is a 36-channel H.265 NVR with 16 PoE ports , designed for large and high-capacity IP video surveillance systems. It supports resolutions up to 8MP , 4K UHD HDMI output, VGA and H.265/H.264 compression, with network bandwidth up to 320 Mbps in and 320 Mbps out . It integrates a microphone and speaker for two-way audio, automatic pairing of Imou cameras and ONVIF 20.12 compatibility. It offers motion, people and vehicle detection, remote management via the Imou App and Dual-Bay storage with 2 SATA ports up to 16 TB per HDD . The 16 IEEE 802.3af/at PoE ports provide a total power of up to 150 W , for efficient management of numerous IP cameras. Imou

Technical Data Sheet

Reference: NVR-N236-16P-8A0E-P-IMOU

Brand: IMOU

EAN: 6937479645491

Manufacturer Object ( [id] => 41 [name] => IMOU [description] =>

Imou uses smart and easy-to-use technologies designed for home and small and medium-sized business security. All systems are compatible with Alexa and Google Home, if you want to monitor what matters for you the most, all you have to do is ask the device to show you the images.

[short_description] =>


Imou was created with the aim of proposing intelligent solutions that enable everyone to enjoy a more comfortable and safer life, simplifying everyday life for consumers, as highlighted by the official claim: 'Enjoy Smart Life'.

[id_address] => [date_add] => 2020-01-14 16:31:52 [date_upd] => 2026-02-19 17:36:36 [link_rewrite] => imou [meta_title] => Imou [meta_keywords] => [meta_description] => Imou was created with the aim of proposing intelligent solutions that enable everyone to enjoy a more comfortable and safer life, simplifying everyday life for consumers [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 1 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
FIND INSTALLER

NVR-N236-16P-8A0E-P-IMOU | 36-CHANNEL POE NVR WITH 4K OUTPUT AND BUILT-IN AUDIO



The Imou N236-16P is a 36-channel H.265 NVR with 16 PoE ports , designed for large IP video surveillance systems. It supports resolutions up to 8MP , 4K UHD HDMI output, VGA and H.265/H.264 compression, with network bandwidth up to 320 Mbps input and 320 Mbps output . It integrates a microphone and speaker for two-way audio, automatic pairing of Imou cameras and ONVIF 20.12 compatibility. It offers motion, people and vehicle detection, remote management via the Imou App and Dual-Bay storage with 2 SATA HDDs up to 16 TB each . The 16 IEEE 802.3af/at PoE ports deliver up to 150 W in total , ensuring efficient management of numerous IP cameras.


Main specifications:

  • Channels: 36 total, 16 PoE
  • Resolution: up to 8MP
  • Video: H.265/H.264, HDMI 4K
  • Storage: 2 HDDs up to 16 TB each
  • Network: 320 Mbps in/out
  • Audio: microphone + speaker
  • AI: motion, people, vehicles
  • PoE: 16 ports, 150W total
  • Compatibility: ONVIF 20.12

Further details


✅ Number of Channels:
 The Imou N236-16P supports up to 36 IP channels , with 16 built-in PoE ports , making it suitable for centralized management of video surveillance systems with numerous cameras.
✅ Resolution:
It supports cameras with resolutions of 8MP, 6MP, 5MP, 4MP, 3MP, 1080p and 720p , with the ability to decode up to 4 channels 8MP at 15 fps or 10 channels 1080p at 30 fps .
✅ Mass Storage :
 The Dual-Bay Massive Storage system integrates 2 SATA ports and supports mechanical HDDs up to 16 TB per single bay , offering up to 32 TB of total installable capacity and backup via USB Flash Drive.
✅ Automatic Pairing:
 The auto -pairing function allows the NVR to automatically connect to compatible Imou cameras , simplifying setup and speeding up the installation of the video surveillance system.
✅ H.265 up to 4K UHD:
 H.265 video compression up to 4K UHD allows you to store more data while maintaining higher video quality , improving overall system efficiency.
✅ Third Party Agreement:
 ONVIF 20.12 compatibility facilitates the integration of the NVR with compatible third-party cameras and IP devices , increasing flexibility in system configuration.
✅ Built-in Mic and Speaker:
 With a built-in microphone and speaker , the NVR supports two-way audio , allowing voice communication without requiring additional audio devices.
✅ HDMI/VGA Output:
 It features 1 HDMI output up to 4K (3840×2160) and 1 VGA output up to 1920×1080 , offering compatibility with different monitors and displays for local viewing of video surveillance.
✅ PoE:
 It integrates 16 10/100 Mbps IEEE 802.3af/at PoE ports , with a total power of up to 150 W and a maximum of 25.5 W per single port , to power and connect IP cameras via Ethernet.
✅ Network:
 It offers a network bandwidth of up to 320 Mbps incoming and 320 Mbps outgoing , 10/100/1000 Mbps Gigabit RJ-45 port, support IPv4/IPv6, HTTP/HTTPS, TCP/IP, DHCP, DNS, P2P and remote management via Imou App for iOS and Android .

Technical Data Sheet

Model NVR-N236-16P-8A0E-P-IMOU
Video & Audio
Access Channel 16PoE Port & 36 channels
Network Bandwidth 320 Mbps incoming and 320 Mbps outgoing
Playback Decoding 4-channel 8 MP@15 fps;
4-channel 6 MP@25 fps;
4-channel 5 MP@30 fps;
5-channel 4 MP@30 fps;
10-channel 1080p@30 fps
Video Compression H.265/H.264
Audio Compression AAC
Backup File Format MP4
Live Display 1,4,8,9,10,16,18,19,25,36
Network
Network Protocol HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; DHCP; DNS;UPnP; DDNS; IP Search (Supports IP camera, DVR, NVS, etc.); Multicast; P2P
Compatible APP IMOU APP (IOS＆Android)
Third Party Agreement Onvif 20.12
Special Features
IPC Connection Automatically connect to IMOU cameras
Smart Detection Motion / Person / Vehicle
Remote Upgrade Yes
Sound Channel Two-Way Audio
External Interface
Video Output 1*HDMI:4K (3840 × 2160), 2K (2560 × 1440), 1920 × 1080, 1600 × 1200, 1280 × 1024, 1280 × 720
1*VGA:1920×1080, 1280×1024, 1280×720
Audio Input 1*Microphone(Built-in)
Audio Output 1*Speaker(Built-in)
USB Interface 2*USB
Reset Button Yes
Network Interface 1 RJ–45 port (10/100/1000 Mbps)
PoE Port 16PoE Ports(10/100Mbps, IEEE 802.3 af/at)
Storage
Hard Drive Capacity 2 SATA ports, up to 16 TB
Backup Media USB Flash Drive
General
Power Supply 100–240 VAC, 50/60 Hz
Power Consumption Total output of NVR is ≤ 9W (without HDD)
Total output power of PoE is 150 W, the maximum output power of a single port is 25.5W
Working Temperature -10℃~+45℃
Working Humidity Less Than 95%RH
Dimensions (L×W×H) 320.0mm×374.0mm×45.0mm
Certification THERE IS
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
