XVR ONVIF® 16-channel 5in1 5M-N - 1080p - 8 IP channels and 16 analog channels - POS and IOT - Video Analysis
XVR5116HE - I3 - Dahua 1xHDMI, 1xVGA, 2xUSB, RS485, RJ45 (1000M) - Support for 1 HDD SATA 3.5" for Audio/Video (max 16TB, not included) - Audio 16-ch RCA and 16-ch BNC in & 1-ch RCA out - Alarm 16-ch in & 3-ch out - IoT & POS and Video Analytics Technology - Supports facial recognition - SMD Plus.
DAHUA: LOSS LEADER×
INCREDIBLE DISCOUNTS
on a selection of DAHUA products
Check out the promo now >>
CLEARANCE SALE ×
CLEARANCE SALE!
Take advantage of our must-see outing offers.
Discover the promo >>
XVR ONVIF® 16 CHANNELS 5IN1 "HDCVI/HDTVI/AHD/ANALOG/IP" - 5M-N RESOLUTION - DAHUA - XVR5116HE-I3

5 in 1: "HDCVI/HDTVI/AHD/Analog/IP" - 8 IP channels and 16 analog channels - 5M-N resolution - Video up to H.265+ with AI Coding / Dual Stream Video / 1xHDMI (4K) - 1xVGA (1080p) - 2xUSB - 1xRS485 - 1xHDD mountable up to 16TB! (not included)
Connection to POS - IoT - Video Analytics with Face Detection (on database up to 20,000 records) - Perimeter protection - SMD Plus - 1in/1out two-way RCA audio - 16xBNC audio (coaxial) - RJ-45 1000M - RS-485 - 24 month warranty

Product details

![]() | DAHUA X SERIES If you want to learn more about this new series of Dahua 5-in-1 XVR recorders , read the article we wrote! |
![]() | 5 Technologies in 1! This DVR supports 5 different technologies ( HDCVI-HDTVI-AHD-ANALOG-IP ) |
![]() | Onvif is the most important standard in the IP world. Being Onvif guarantees a wide range of IP devices compatible with each other (DVR/cameras). This XVR supports ONVIF® version 16.12 |
![]() | 16 channels with resolution 5M-N! Up to 32 channels maximum: 16 IP channels and 16 analog channels (analog channels are converted to IP channels) |
![]() ![]() | This XVR supports compression standards up to H.265+ H.265+: What are the advantages? - Save up to 90% on bandwidth - Reduction of storage space - Longer recording times on analog surveillance systems with the same storage space.
|
![]() | Dahua has released the new GUI 4.0! GUI-XVR 4.0: After more than a year of design and development, the next-generation graphical user interface, XVR4.0, has been released. Beautiful and simple, XVR4.0 ensures perfect viewing. The color schemes, flat interface, and visual icons present a user-friendly experience. Integrated functional modules and logic to simplify user operation and improve product competitiveness. |
![]() | Supports cameras: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more... (the functioning with the models proposed here must be verified on a case-by-case basis) |
VIDEO ANALYSIS (IVS) - Perimeter Protection - SMD Plus - Face recognition | |
![]() | Possibility of connecting POS devices, obtaining all the information overlaid on the channel. POS search possibility by date or transaction |
![]() | Supports 1x 3.5" SATA Audio / Video Hard Disk up to 16TB!
HARD DISK NOT INCLUDED! |
![]() ![]() | HDMI port with resolution up to 4K |
![]() | VGA output with resolution up to 1080P |
![]() | This DVR features 1 Audio IN and 1 Audio OUT RCA 16 Channel Coaxial BNC Audio |
![]() |
This DVR features 2x USB Ports ((1 USB 2.0,1 USB 3.0) |
![]() | This DVR features 1 RJ45 LAN Ethernet Port (1000M) |
![]() | RS 485 for PTZ Controls (Remotely controllable cameras) |
![]() | Dynamic DNS: allows you to reach the DVR even in the case of a dynamic IP |
![]() | Ability to overwrite the disk when it is full or have the disk overwrite after X days. DVR restart schedule to ensure greater stability over time. |
![]() | This XVR has email sending. |
![]() | Motion function. Recording starts when the camera detects motion. |
![]() | This product is covered by a 24 month warranty. |
Technical data sheet
XVR5116HE-I3 | |
Technical Specs | |
System | |
Main Processor | Embedded processor |
Operating System | Embedded Linux |
Operating Interface | Web; Local GUI |
Perimeter Protection | |
Perimeter Performance AI by Recorder (Number of Channels) | Advanced Model: 2 channels, 10 IVS for each channel General Model: 8 channels, 10 IVS for each channel |
Face Detection | |
Face Attributes | Gender; age group; glasses; expressions; face mask; beard |
Face Detection Performance of Aby Recorder (Number of Channels) | 2 channels (up to 12 face images/s) |
Face Recognition | |
Face Database Capacity | Up to 10 face databases with 10000 face images in total. Name, gender, birthday, address, certificate type, cerificate No., countries®ions and state can be added to each face picture |
Face Recognition Performance of AI by Recorder (Number of Channels) | 2 channels |
SMD Plus | |
SMD Plus by Recorder | 16 channels: Secondary filtering for human and motor vehicle SMD Plus, reducing false alarms caused by leaves, rain and lighting condition change |
Audio and Video | |
Analog Camera Input | 16 BNC ports, CVI access by default, supports HDCVI/ AHD/TVI/CVBS auto-detect |
Camera Input | 1. CVI: 5MP, 4MP, 1080p@25/30fps, 720p@50/60fps, 720p@25/30fps. 2. TVI: 5MP, 4MP, 3MP, 1080p@25/30, 720p@25/30 fps. 3. AHD: 5MP, 4MP, 3MP, 1080p@25/30, 720p@25/30 fps. |
IP Camera Input |
Lower than 12 W |
Net Weight | 1.15 kg (2.54 lb) |
Gross Weight | 1.95 kg (4.30 lb) |
Product Dimensions | Mini 1U, 325.0 mm × 257.1 mm × 55.0 mm 12.80" × 10.12" × 2.17" (W × D × H) |
Packaging Dimensions | 372.0 mm × 117.0 mm × 308.0 mm 14.65" × 4.61" × 12.13" (W × D × H) |
Operating Temperature | –10 °C to +55 °C (+14 °F to +131 °F) |
Operating Humidity | 10%–90% |
Installation | Desktop; (Some Models) |
Certifications | CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024 FCC: Part 15 Subpart B |
