NVR 64 IP CHANNELS - ONVIF® DAHUA - 4K SERIES ARTIFICIAL INTELLIGENCE - UP TO 24MP MEGAPIXEL - 8HDD SATA 10TB - HDMI -VGA - NVR5864-I/L

NVR IP ONVIF® 64 Channels - New 4K AI Series - Dahua - NVR5864-I/L
Up to 24MP resolution - 320Mbps maximum bandwidth - H.265+ video compression
Output 2xHDMI ( 4K ) - VGA - 2 USB2.0/ 2 USB 3.0 - Audio 1in/1out RCA - Alarm 16in/6out - Up to 8 SATA HDDs of 10TB each.
Artificial Intelligence: Perimeter Protection, Face Recognition, Metadata, People Counting, ANPR, Heat Map - 2xRJ45 1000M - RS232 - RS485 - Smart Fan - Multibrand Support.
  AI TECHNOLOGY | ARTIFICIAL INTELLIGENCE:  |
Product details

  |  AI NVR Recorders with Artificial Intelligence Available AI functions:  1) PERIMETER PROTECTION:  2) FACIAL RECOGNITION:  3) METADATA  4) PEOPLE COUNTING  5) ANPR 6) HEAT MAP

  |
  | Smart H.265+ Smart H.265+ is the optimized implementation of H.265 codec that uses scene-adaptive coding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure and intelligent noise reduction to deliver high-quality video without straining the network. Smart H.265+ greatly reduces bit rate and storage requirements compared to standard H.265 compression
  |
![]()  |  New ULTRA HD 4K Technology! Even higher resolution than FULL-HD! Greater detail available, greater sense of depth and realism.  |
| RS 485 for PTZ commands (remotely controllable cameras) | |
![]()  | RS 232 to communicate with PC and keyboard |
![]()  | This NVR supports ONVIF® Profile S standard  |
![]()  |  64 IP channels with H.265+ codec:  |
![]()  |  Support IP cameras: Arecont Vision, Airlive, AXIS, Canon, Dynacolor, JVC, LG, Panasonic, Pelco, Xunmei, Samsung, Sanyo, Sony, Watchnet and more... (operation with the models proposed here is to be checked on a case-by-case basis)  |
Cloud function with Easy4IP    | |
 Compatible with Mobile devices: iPhone, iPad, Android ![]()  | |
|  Supports 8x SATA III Hard Drives up to 10TB each (hard drives not included) ATTENTION: use specific audio/video discs on NVR systems. For more information, read our dedicated article .  | |
![]()  | This NVR features 4 USB ports (2x2.0 front + 2x3.0 rear) |
![]() ![]()  | Resolution up to 4K via HDMI port!
  New ULTRA HD 4K Technology!  |
![]()  | With alarm relay 16 inputs and 6 outputs for inputs from burglar alarms or other instruments and for activating external peripherals (gates, sirens, etc.) |
| This NVR has 1 RCA audio input and 1 RCA audio output | |
| Dynamic DNS: allows you to reach the NVR even in case of dynamic IP | |
![]()  | Ability to have the disk overwrite when full or have the disk overwrite after X days. NVR restart programming to ensure greater stability over time |
![]()  |  This NVR has email sending. In case of events (camera obfuscation, signal cut, motion, broken disk, network problems etc ...), it is able to send an email notification, a sound notification or upload video & screeshot via FTP  |
![]()  | Motion function. Recording starts when the camera detects movement. |
![]()  | 2x RJ-45 (10/100/1000Mbps) |
This product is covered by a 24 month guarantee.  |
Data sheet
| NVR5864-I/L | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
System  | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
main processor  | Multi-core embedded processor  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating System  | Embedded LINUX  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
perimeter protection  | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Performance  | 12 channels, 10 IVS rules for each channel  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Object classification  | Human/Vehicle secondary recognition for tripwire and intrusion  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
AI Search  | Search by target classification (Human, Vehicle)  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Recognition  | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Performance  | Max 16 face pictures/sec processing (modeling and comparing)  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
4 channel video stream face recognition/16 channel picture stream face recognition (with FD camera)  | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Strange Mode  | Detect strangers' faces (not in device's face database).  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
AI Search  | Up to 8 target face images search at same time, similarity threshold can be set for each target face image.  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Database Management  | Up to 20 face databases with 200,000 face images in total. Name, gender, birthday, nationality, address, ID information can be added to each face picture.  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Database Application  | Each database can be applied to video channels independently.  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Trigger Events  | Buzzer, Voice Prompts, Email, Snapshot, Recording, Alarm Out, PTZ Activation, etc.  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Metadata  | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 8 SATA III ports, up to 10TB for a single HDD. The maximum HDD capacity varies with environment temperature  | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
eSATA  | 1 eSATA  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Auxiliary Interface  | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
USB  | 4 USB Ports (2 Rear USB 3.0, 2 Front USB 2.0)  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RS232  | 1 Port, for PC Communication and Keyboard  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RS485  | 1 Port, for PTZ Control  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electrical  | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply  | Single, AC100V–240V, 50–60Hz  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
power consumption  | NVR: <16.1W (Without HDD)  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Fan  | Smart fan, automatically adjust running speed  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
environmental  | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Conditions  | -10°C to +55°C (+14°F to +131°F), 86–106kpa  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Conditions  | 0°C to +40°C (+32°F to +104°F), 30–85% RH  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Construction  | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dimensions  | 2U, 439.7mm × 451.0mm × 94.9mm (17.31" × 17.75" × 3.73")  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight  | 6.70 kg (14.8 lb) (without HDD)  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight  | 9.30 kg (20.5 lb) (without HDD)  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certifications  | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
THERE IS  | EN55032, EN55024, EN50130-4, EN62368-1  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
FCC  | Part 15 Subpart B, ANSI C63.4-2014  | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
