iDS-7204HTHI-M1/S - HIKVISION - TURBO HD DVR - 4 IP channels - 4 analog channels - Up to 8MP - H.265 Pro+ - Bidirectional Audio

-58%

HIKVISION | TURBO HD DVR iDS-7204HTHI-M1/S - ONVIF - 5in1 (HDTVI/AHD/CVI/CVBS/IP) - 4 IP channels up to 8MP 4K ULTRA-HD, 4 analog channels - H.265 Pro+ video compression to take full advantage better digital storage capacity, up to 10TB SATA HDD (each) ( includes 1TB HDD ), 4 inputs + 1 audio output via coaxial, 1 bidirectional audio channel, Dual Stream, VCA Video analysis, Intrusion Detection, Detection Line Crossing, Smart Search, Hik-Connect Application. Ideal for video surveillance systems.

Reference: iDS-7204HTHI-M1/S

Brand: Hikvision

https://www.setik.biz/en/recording-devices/8406-hikvision-ids-7204hthi-m1-s-ids-7204hthi-m1s-hikvision-turbo-hd-dvr-4-ip-channels-4-analog-channels-up-to-8mp-h265-pro-bidirectional-audio.html

€303.34

€722.24 -58%

taxes included

ARE YOU A PROFESSIONAL OF THE SECTOR?
REGISTER TO ACCESS YOUR LIST

OFFICIAL AJAX DISTRIBUTORS! ×

BUY AJAX!
Free shipping >€49
SPED-AJAX-E

Description Product Details Data Sheet Further Details Download

iDS-7204HTHI-M1/S | 5IN1 (HDTVI/AHD/CVI/CVBS/IP) TURBO HD DVR HIKVISION - H.265 PRO+ - AUDIO + SATA INTERFACE HDD UP TO 10TB - ONVIF®

HDD

1TB HARD DISK INCLUDED!

By purchasing this Hikvision recorder you will already find a 1TB capacity hard disk included, specific for video surveillance applications

Turbo HD DVR - Hikvision iDS-7204HTHI-M1/S - 5in1 (HDTVI/AHD/CVI/CVBS/IP) - Up to 4 IP input channels - 4 analog channels -

Resolution: up to 8MP 4K ULTRA-HD 8Megapixel - H.265 Pro+ video compression - Up to 1 SATA HDD of 10TB (each) - 4x Input and 4x Output audio, Video Analysis, Intrusion Detection, Line Crossing Detection, Smart Search, Dual Stream, Hik-Connect Application - RJ45 10m/100m/1000m LAN interface - Possibility of mobile remote control - 24 months warranty - Ideal product for use in video surveillance systems.

4K TECHNOLOGY - ULTRA HD - WHAT DOES IT MEAN?
4K technology (also known as ULTRA HD ) is one of the latest innovations in the field of high definition vision. 4K corresponds to the resolution of 4 Full-HD, so 3840 X 2160! Already used in the consumer electronics sector, it is finally arriving in the world of security as well. The new generation of DAHUA devices, in fact, allows the support of cameras up to 12MPX on standard H265 , the new video compression that allows you to save up to 50% compared to the previous H264. Thanks to the 4K output it is also possible to view (on a 4K monitor) the image with its maximum detail.

4K TECHNOLOGY - ULTRA HD - WHAT DOES IT MEAN?

4K Ultra HD technology 4K technology (also known as ULTRA HD ) is one of the latest innovations in the field of high definition vision. 4K corresponds to the resolution of 4 Full-HD, so 3840 X 2160!
Already used in the consumer electronics sector, it is finally arriving in the world of security as well. The new generation of DAHUA devices, in fact, allows the support of cameras up to 12MPX on standard H265 , the new video compression that allows you to save up to 50% compared to the previous H264. Thanks to the 4K output it is also possible to view (on a 4K monitor) the image with its maximum detail.

4 IP CHANNELS and 4 ANALOG CHANNELS -
5IN1 FUNCTION:

4 analogue channels and 4 IP channels up to 4K ULTRA-HD 8 Megapixel
Recording resolution: 8MP

5in1 ( HDTVI/AHD/CVI/CVBS/IP )!

4K ULTRA-HD RESOLUTION:

ULTRA HD 4K technology!
Even higher resolution than FULL-HD!
Greater detail available, greater sense of depth and realism thanks to the images with extraordinary definition, so as not to miss any detail!

H.265 Pro+ VIDEO COMPRESSION:

H.265 Pro+ is the optimized implementation of H.265 codec that uses scene-adaptive coding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure, and intelligent noise reduction to deliver high-quality video without strain the network. Smart H.265+ greatly reduces bit rate and storage requirements compared to standard H.265 compression
Video compressione Smart H.265+

VIDEO ANALYSIS:
Behavior Analysis (available on all Channels):
- Line crossing detection
- Intrusion

SMART SEARCH:
This function allows you to obtain various motion videos in a short time by simply drawing an area during playback. Very useful in case he should understand an emergency

Smart Search Banners

HIK-CONNECT

Hik Connect allows you to control the device remotely

RJ45:

1x RJ-45 (10/100/1000Mbps) Gigabit

HARD DISKS:

Supports up to 1 SATA III HDD, up to 10TB (each) capacity.

USB:

1× USB 2.0 (front panel); 1x USB 3.0 (Back panel)

Audio:

This DVR features 4 audio inputs + 1 audio output, 1 two-way audio channel, 1 RCA input channel!

Data sheet

iDS-7204HTHI-M1/S
Motion Detection 2.0
Human/Vehicle Analysis	Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; Quick search by object or event type is supported;
perimeter protection
Line Crossing Detection/ Intrusion Detection	4-ch
recording
video compression	H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Encoding resolution	8MP/5MP/3K/4MP/3MP/1080p/720p/WD1/4CIF/VGA/CIF
Frame rates	Main stream: 8MP@15fps/8MP@12fps/3K@20fps/5MP@20fps/5MP@12fps/3MP@18fps 4MP/1080p/720p/WD1/4CIF/VGA/ CIF@25fps (P)/30fps (N) Sub-stream: WD1/4CIF/CIF@25fps (P)/30fps (N)
Video bit rate	32Kbps to 16Mbps
Dual streams	Support
Stream type	Videos, Videos & Audios
Audio compression	G.711u
Audio bit rate	64Kbps
Video and Audio
Video input IP	4-ch (up to 8-ch)
	Up to 8MP resolution 8MP Resolution
	Support H.265+/H.265/H.264+/H.264 IP cameras
Analog video input	4-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
HDTVI inputs	8MP@15fps, 8MP@12.5fps, 3K@20fps, 5MP@20fps, 5MP@12fps, 4MP@30fps, 4MP@25fps, 3MP@18fps, 1080p@30 fps, 1080p@25fps, 720p@60fps, 720p@50fps, 720p@30fps, 720p@25fps
AHD input	5MP@20fps, 4MP@25fps, 4MP@30fps, 1080p@25fps, 1080p@30fps, 720p@25fps, 720p@30fps
HDCVI input	4MP@25fps, 4MP@30fps, 1080p@25fps, 1080p@30fps, 720p@25fps, 720p@30fps
CVBS input	PAL/NTSC
CVBS output	1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
VGA output	1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
HDMI out	1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
Video output mode	HDMI/VGA independent outputs
Audio inputs	1-ch, RCA (2.0 Vp-p, 1KΩ) 4-ch via coaxial cable
Audio outputs	1-ch, RCA (Linear, 1KΩ)
Two-way audio	1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
Synchronous playback	4-ch
Network
Total Bandwith	96Mbps
Remote connections	32
Network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF®
Network interface	1, RJ45 10M/100M/1000M self-adaptive Ethernet interface
Wifi	Connectable to Wi-Fi network by Wi-Fi dongle through USB interface
Auxiliary interface
SATA	1 SATA interface
Capacity	Up to 10TB capacity for each disk
Serial interface	RS-485 (half duplex)
USB interface	Front panel: 1 × USB 2.0 Rear panel: 1 × USB 3.0
Alarm in/out	N/A
General
power supplies	12VDC, 2A
consumption (without HDD)	≤ 10W (without HDD)
Working temperatures	-10°C to +55°C (+14°F to +131°F)
Working humidity	10% to 90%
Dimensions (W×D×H)	315×242×45mm (12.4×9.5×1.8inch)
Weights (without HDD)	≤ 1.8 kg (without HDD, 4.0 lb.)
