DS-KD-KK - The KD8 Pro Modular Door Station series button panel module is designed for professional modular video intercom systems, offering 6 call buttons with nameplates for simple and immediate access management in apartment buildings and multi-user facilities. Its IP65 protection ensures high resistance to dust and atmospheric agents, making it ideal for outdoor installations. Based on a Linux operating system with a high-performance embedded processor, it ensures reliability and seamless integration with Hikvision KD8 Pro modules. Thanks to backlight compensation behind the buttons, low power consumption, and the option of flush-mounting or surface-mounting, it represents a modern, expandable, and easy-to-use solution. Hikvision
DS-KD-KK – KD8 PRO MODULAR DOOR STATION SERIES

The Hikvision DS-KD-KK button panel module from the KD8 Pro Modular Door Station series is ideal for professional modular video intercom systems thanks to its 6 buttons with backlit nameplates , designed to facilitate calls in apartment buildings and multi-user facilities. The IP65 -rated structure guarantees resistance to dust, rain and harsh weather conditions, making it perfect for outdoor installations. Equipped with a Linux operating system and a high-performance embedded processor, it ensures operational stability and advanced integration with Hikvision KD8 Pro systems. The option of flush-mounted or surface-mounted installation, combined with low power consumption and the RS-485 interface, make it a modern, expandable and easy-to-use solution.
Main features:
- Module with 6 call buttons for multi-user management in condominiums and homes
- Backlit name tags for optimal visibility even in low light conditions
- IP65 protection resistant to dust, water and outdoor installations
- Linux system with embedded processor for stable and reliable performance
- Integrated RS-485 interface for integration with modular video intercom systems
- Flush or surface installation for maximum mounting flexibility
- Low power consumption ≤ 2 W ideal for efficient security systems
- Expandable modular design compatible with professional Hikvision video intercoms and accessories
Further details
Backlit nameplates ensure high readability of names even at night or in low-light environments. Thanks to integrated backlight compensation, the system ensures a clear and professional display, improving the user experience and the aesthetics of the video intercom entry panel.
Technical data sheet
| DS-KD-IN | |
| System parameters | |
| Processor | Embedded high performance processor |
| Device interfaces | |
| Alarm input | / |
| Network interface | / |
| TAMPER | / |
| Exit button | / |
| RS-485 | 1 |
| USB | / |
| Wiegand | / |
| TF card | / |
| Alarm output | / |
| Door contact input | / |
| General | |
| Button | 6 |
| Installation | Flush mounting, surface mounting |
| Weight | Net weight: 190 g Gross weight: 438 g |
| Protective level | IP65 |
| Working temperature | -40° C to +55° C(-40° F to 131° F) |
| Working humidity | 10% to 95% |
| Dimensions | 98.5 mm × 100 mm × 34.2 mm (3.87" × 3.95" × 1.33") |
| Battery | / |
| Application environment | Outdoor |
| Power consumption | ≤ 2 W |
