Hikvision 2MP WiFi QR PoE IP65 Face Recognition Access Control Terminal with Two-Way Audio

Hikvision 2MP WiFi QR PoE IP65 Face Recognition Access Control Terminal with Two-Way Audio

-35% New

DS-K1T323MBWX-QRE1 - The terminal is an advanced solution for access control, equipped with a 2.4-inch display and a 2 MP camera with a wide-angle lens , designed to ensure rapid and accurate identification. Thanks to the capacity of up to 1000 faces and 3000 cards and a recognition time of less than 0.2 seconds , it ensures high performance in high-traffic environments. It supports multiple authentication via face, badge and QR code , as well as two-way audio for real-time communication. Connectivity is guaranteed by Wi-Fi, LAN and PoE , with management via Web and AP mode. Ideal for outdoor installations thanks to IP65 protection and WDR technology , it offers reliability and advanced security for professional systems. Hikvision

Technical Data Sheet

Reference: DS-K1T323MBWX-QRE1

Brand: Hikvision

EAN: 6936422110338

Manufacturer Object ( [id] => 42 [name] => Hikvision [description] =>

Since the year of its birth, its prestige has grown so much that in 2015 it will become the first global reality in security.

From 2016 Hikvision expands its market becoming Total Solution Provider for the entire security market. Thus it enters the world of intrusion detection and then approaches new technologies and intelligence at the service of mankind by dealing with IoT, Machine Vision, Robotics and Automotive systems. From security leader, Hikvision becomes with commitment, passion and competence a Hi-Tech company with a vision 4.0, always aiming high.

Setik is therefore honored to be a Hikvision distributor. We will, as always, offer the latest generation products and the appropriate technical and commercial support.

[short_description] =>

Videosorveglianza Hikvision

Hikvision was founded in 2001 with the aim of creating and developing complete professional video surveillance solutions, quickly becoming a leader in the security world.

[id_address] => [date_add] => 2020-03-26 09:28:09 [date_upd] => 2024-06-06 12:13:26 [link_rewrite] => hikvision [meta_title] => Security Hikvision [meta_keywords] => Hikvision, Security Hikvision [meta_description] => Hikvision was founded in 2001 and soon became a leader in the world of video surveillance. Discover now the products in the catalogue! [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 1 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
FIND INSTALLER


DS-K1T323MBWX-QRE1 – VALUE SERIES FACE ACCESS TERMINAL

Hikvision

The Hikvision DS-K1T323MBWX-QRE1 terminal is an advanced access control solution, equipped with a 2.4-inch display and 2 MP camera with wide-angle lens , designed to ensure rapid and accurate identification. It offers capacity for up to 1000 faces and 3000 cards , with rapid facial recognition (<0.2 s) and an accuracy of over 99%, ideal for high-traffic environments. It supports multiple authentication via face, M1 badge and QR code , as well as two-way audio for real-time communication. It integrates Wi-Fi, Bluetooth, LAN and PoE power supply , with web configuration and AP mode. The robust structure with IP65 protection and WDR technology ensures reliability even in difficult conditions.

Main features:

- 2.4" display with 240×320 resolution

- 2 MP camera with wide angle lens

- Capacity 1000 faces and 3000 cards

- Facial recognition <0.2 s="" and="" accuracy="">99%

- Multiple authentication: face, M1 card and QR code

- Wi-Fi, Bluetooth, LAN 10/100 Mbps and PoE

- Integrated two-way audio

- IP65 protection for indoor and outdoor environments

- Support WDR and anti-face spoofing


Further details

Touch Display :
Equipped with a 2.4-inch TFT screen with 240×320 resolution , it offers clear information display and a simple interface for managing access operations.
Capacity :
It supports up to 1000 users/faces, 3000 cards and 150,000 events , ensuring efficient data management even in high-traffic contexts with numerous accesses.
Authentication :
It integrates high-precision facial recognition (>99%) , M1 card reading (13.56 MHz) and QR code , offering multiple and secure access methods with extremely fast recognition times (<0.33 s="" span=""> .
Functions :
It includes two-way audio , face anti-spoofing , voice notifications, and support for web and AP mode configuration , ensuring advanced security and easy operational management .
Interfaces :
It features RJ45 network port , Wiegand , lock control , exit button input , door contact and tamper , ensuring complete integration with professional access control systems .
Network :
It offers full connectivity with Wi-Fi, Bluetooth and 10/100 Mbps LAN , as well as IEEE802.3at PoE power supply , ensuring flexible installation and stable communication in IP environments .

Technical data sheet

DS-K1T323MBWX-QRE1
System parameters
Operating system Linux
Display parameters
Screen size 2.4-inch
Resolution 240 × 320
Type TFT
Operation method Non-touchable
Video
Resolution 2MP (video stream:540P)
Lens ×1
Standard video PAL (Default) and NTSC
Network
Bluetooth Support
Wired network 10/100 Mbps self-adaptive
Wi-Fi Support
Interface
PoE IEEE802.3at, PoE standard
Network interface 1
Wiegand 1, supports Wiegand input, single direction
Lock control 1
Exit button 1
Door contact input 1
TAMPER 1
Capacity
User capacity

1000

Card capacity

3000

Face capacity

1000

Event capacity

150000

Authentication
Card type M1 card;M1 card content;CPU card No.
Card reading frequency 13.56 MHz
Face recognition duration < 0.33 s
Face recognition accuracy rate >99%
Face recognition distance 0.3 to 1.5 m
General
Button

1 physical call button

Power supply

12 VDC, 1 A, PoE standard

Working temperature

-30 °C to 65 °C (-22 °F to 149 °F)

Working humidity

0% to 90% (no condensation)

Dimensions

157 mm × 52 mm × 26 mm (6.18" × 2.05" × 1.02")

Installation

Wall mounting

Protective level

IP65

Language

English, Spanish (South America), Arabic, Thai, Indonesian, Russian, Vietnamese, Portuguese (Brazil), Turkish, French, Traditional Chinese

Weight

Net weight: 0.22 kg (0.49 lb)
Rough weight: 0.6 kg (1.32 lb)

Function
QR code recognition

Support scan QR code via QR code module

Face anti-spoofing

Support

Two-way audio Support
Audio prompt Support
