HYUNDAI - HYU-677 - Camera video surveillance with Minidomes Illuminator 30m with white light outdoor, 2 MP 25fps resolution and 4mm fixed lens, 1 / 2.8 " 2MP COLOR VIEW CMOS sensor, WDR 120dB , face detection, White balance, OSD, AGC, 3DNR, ROI, BLC, HLC, IP67 - MicroSD slot up to 128GB - Video Compression up to H.265 + for optimal storage space saving - RJ45 - PoE - ONVIF - Metal body - For video surveillance systems.
CLEARANCE SALE ×
 CLEARANCE SALE!
Take advantage of our must-see outing offers.
  Discover the promo >>

HYUNDAI 5 MEGAPIXEL FIXED 4IN1 BULLET CAMERA - IR 20M WITH WHITE LIGHT - WDR 130dB - COLOR VIEW -

HYU-677 - HYUNDAI - 2MP Minidome outdoor camera, COLORVIEW, with 4mm lens and 2MP CMOS sensor
Resolution 2 Megapixel - Fixed lens 4mm - CMOS sensor 1 / 2.8 " 2 MP - Color mode 24h - ONVIF® - PoE - 30 M IR illuminator with white light - WDR 130dB - COLOR VIEW - Triple Stream - MicroSD Slot up to 128GB - Compression of the video up to H.265 + (Maximum storage efficiency available) - Face detection - Smart advanced features - RJ45 - Reset button - Extended 3 Year Hyundai warranty! - IP67 protection (dust / immersion) - Ideal solution for the application in outdoor video surveillance systems - 12V DC power supply (not included)

Product details
|
 HYUNDAI CATALOG: Are you looking for a HYUNDAI product but couldn't find it on our site? Don't worry, we can supply you with ALL Hyundai products: consult the CATALOG or contact us by email.  |
![]()  |
 All Onvif , the absolute standard for IP cameras, being Onvif guarantees compatibility with any modern recording system. NOT being Onvif means having a camera for its own sake that can never be used together with recording systems This camera supports Onvif version  |
![]()  |
The advantage of a PoE camera is obvious, it allows it to be powered with the same cable with which it communicates without bringing additional power cables and without having to install a separate power supply system, a PoE camera guarantees constant voltages and simple installation. |
![]()  |
 This camera features a resolution of 2MP! 2MP 1 / 2.8 "CMOS sensor!  |
|


  |
 CMOS sensor with ColorView Technology ! COLOR VIEW: By adopting a high performance sensor and large aperture lens, this camera is able to provide a more colorful image even in low ambient light conditions. Full-color starlight cameras are perfect for low-light applications that exceed 1 lux, such as parking lots, urban streets, schools, museums, etc. 24H COLOR: This camera has no IR CUT filter. The camera does not switch to B / W but the vision will always be in color.
  |
![]()  |
 Smart H.265 + Smart H.265 + is the optimized implementation of the H.265 codec which uses a scene adaptive coding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure and intelligent noise reduction useful for delivering high quality video without straining the network. Smart H.265 + greatly reduces bit rate and storage requirements compared to standard H.265 compression
  |
![]()  |
 Fixed 4mm lens  |
![]()  |
BLC (BACK LIGHT COMPENSATION) is one of the 3 solutions for managing images with contrast. The BLC function allows a discreet adaptation to all those situations where shooting is difficult (entrances or exits of parking lots, registration of license plates, presence of special lights etc ...) ![]()  |
![]()  |
 This camera provides advanced intelligent functions including. face detection.
  |
![]()  |
This camera is equipped with the ROI function. The images deriving from IP cameras are “compressed”, consequently the quality is set during the recording phase. Especially on cameras with a very high resolution, it is often necessary to reduce the quality in order to guarantee a reduced bandwidth occupation and record a greater number of days or cameras. The ROI allows you to define areas where you can set a higher quality (for example a door, the area where the plate usually passes, an exit, etc.). In that area I can set a higher quality thus guaranteeing me a greater definition of the image. ![]()  |
|

  |
 White light IR illuminator. Maximum range supported up to 30m.  |
|

  |
 The camera has an OSD menu , through which it is possible to manage and adjust some functions such as: WB, AGC, AE, DNR, etc.  |
![]()  |
 ULTRA WDR up to 120dB  |
![]()  |
Day / Night: allows you to adapt the lens to night / day vision, and the relative automatic management of the IR illuminator, when present. ![]()  |
![]()  |
 ATW (Auto Tracing White Balance) refers to a modern technology that automatically and continuously adjusts the color balance of the camera according to the color temperature . ATW is a more advanced feature than AWB (Auto White Balance), and is very important as without it, images could be completely unusable. Possibility to adjust the color balance also manually (MWB)  |
![]()  |
AGC is an integrated signal amplifier that allows vision even in critical conditions. It is automatic and does not require specific settings. |
| Possibility to insert Micro SD up to a maximum of 128GB (Not Included) | |
![]()  |
Protection level IP67 (Dust / Diving)  |
![]()  |
 Arm with movement on 3 axes: 0 ° ~ 360 ° (PAN),  |
![]()  |
A 12VDC power supply is required for the operation of this camera (not included) ![]()  |
![]()  |
This product is covered by a 3 Year Warranty! |
Data sheet
| Model | HYU-677 |
| Image Sensor |
 1 / 2.8 "CMOS sensor, 2 MP  |
| Digital Resolution | 1080P (1920x1080) at 25 ips |
| Video Compression |
 H.265 + / H.265 / H.264 + / H.264 / MJPEG  |
| Stream | Triple Stream:
  |
| Minimum Illumination |
 0.0035 lux F1.0 (color 24 hours)  |
| IR Illumination |
 White illumination up to 30 meters  |
| Lens |
 4mm  |
| Viewing Angle | 89 ° (H), 46 ° (V), 106 ° (D) |
| OSD menu |
 Yes  |
| Advanced |
  |
| Adjustment |
 image rotation, brightness, saturation, contrast, sharpness, gain control and white balance via client software and web browser  |
| Smart Functions |
  |
| Facial Detection |
 Supported  |
| Reset Button |
 90% (without condensation)  |
| Storage |
 MicroSD / SDHC / SDXC up to 128GB (card is not included)  |
| Network Interface |
 RJ45 (10/100 Base-T)  |
| Network protocols |
 TCP / IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1x, QoS, IPv6, UDP, Bonjour  |
| Compatibility |
 ONVIF® (Profile S, G), ISAPI, DDNS DEMES  |
| Plug & Play |
 NEXTGEN NVR  |
| Power Supply |
 12V DC  |
| Consumption | 0.5A, max. 6W |
| PoE | 802.3af, Class 3 |
| Working Temperature | -30 ° C ~ + 60 ° C |
| RH | 95% (without condensation) |
| Protection | IP67 |
| Material | Metal Case |
| Dimensions | Ø138.3 x 125.2 (Al) mm |
| Weight | 575g |
| 3AXIS | 0 ° ~ 360 ° (PAN), 0 ° ~ 75 ° (TILT), 0 ° ~ 360 ° (Rotation) |
| Power Supply | not included |
