The TP-Link Omada SM6110-LR is a QSFP28 transceiver module offering 10G and 25G Ethernet connections up to 10 km over 9/125µm single-mode fiber, ensuring high performance and maximum reliability. Designed with a duplex LC interface, it supports digital diagnostic monitoring (DDM) and integrates Clock & Data Recovery functions for stable transmission. With low power consumption ≤1.2W and compatibility with IEEE standards and protocols such as eCPRI and CPRI, it ensures efficiency and flexibility. The hot-swappable design facilitates installation, making it ideal for data centers, enterprise networks, and cloud applications. CE, FCC, and RoHS certified, it is a safe and regulatory-compliant solution. Omada

Technical Data Sheet

Reference: SM6110-LR

Brand: OMADA

EAN: 8885020622355

Manufacturer Object ( [id] => 53 [name] => OMADA [description] =>

A key aspect of OMADA is its ability to offer centralised management. This can be done through a dedicated hardware controller, a software controller, or the Omada SDN cloud service, which enables centralised management of networks. The solutions offered are scalable and flexible, making them suitable for both small corporate networks and large multi-site deployments.

OMADA includes wireless solutions with high-performance Wi-Fi access points, ensuring reliable, high-speed coverage. In addition, it offers managed switches and gateway routers with advanced traffic management, security and quality of service (QoS) features.

Security is another strong point of OMADA's solutions, which include advanced features such as firewalls, VPNs and access control to protect corporate networks. In addition, OMADA's cloud platform enables remote configuration and monitoring of networks, offering great flexibility in IT management.

For businesses, OMADA provides a solution that can reduce operating costs through centralised management that simplifies network maintenance. High-quality hardware components ensure stable and reliable performance, while intuitive interfaces and management tools make network administration easier even for non-technical staff.

OMADA's core products include indoor and outdoor access points with advanced technologies such as Wi-Fi 6, managed switches with Layer 2 and Layer 3 capabilities, and security and routing devices for network traffic management and threat protection. OMADA solutions are commonly used in corporate offices to manage internal networks, in schools and universities to provide Wi-Fi connections for students and staff, and in hotels to offer a stable and fast Internet connection to guests.

[short_description] =>

Tp-Link Omada

OMADA is a TP-Link brand of enterprise network management solutions. The OMADA system includes both hardware and software designed to centralise the management of wireless networks, switching and gateways. This approach is designed to improve the control and management of network infrastructures, particularly in enterprise environments.

[id_address] => [date_add] => 2024-06-13 09:45:42 [date_upd] => 2025-08-25 11:30:31 [link_rewrite] => omada [meta_title] => [meta_keywords] => [meta_description] => [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 1 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
FIND INSTALLER


CLEARANCE SALE ×


 CLEARANCE SALE!
Take advantage of our must-see outing offers.
  Discover the promo >>

SM6110-LR | QSFP28 MODULE WITH 10G AND 25G ETHERNET CONNECTIONS UP TO 10KM


Made Omada

The TP-Link Omada SM6110-LR SFP28 transceiver is designed to provide 10G and 25G Ethernet connections up to 10km over single-mode fiber, offering maximum performance, reliability, and low power consumption. With DDM support and a hot-swappable design, it easily integrates into enterprise networks and data centers, ensuring stability and compatibility with major industry standards.

Main specifications:

- 10G/25G connections up to 10 km on 9/125 µm fiber

- Low power consumption ≤ 1.2 W with 3.3 V power supply

- Support for Digital Diagnostic Monitoring (DDM) and integrated CDR

- Duplex LC connector, IEEE 802.3cc/ae standard, CE, FCC, RoHS

- Hot-swappable design for maximum flexibility

Further details

Single-mode SFP+/SFP28 LC:
It uses 9/125 µm single-mode optical fiber with a duplex LC connector, supporting speeds up to 25.78 Gbps and ensuring stable transmissions up to 10 km. This feature makes it perfect for long-distance networks with high reliability and low latency.
DDM (Digital Diagnostic Monitoring) :
It integrates an advanced diagnostic monitoring system that allows real-time monitoring of key parameters such as optical power, temperature, and voltage, facilitating proactive network management and reducing the risk of malfunctions.
Hot-Pluggable:
The hot-swappable design allows module installation and replacement without interrupting network operation, providing maximum flexibility and reducing downtime in critical environments such as data centers and enterprise infrastructure.

Technical data sheet

Model SM6110-LR
TRANSCRIBER
Standards & Protocols IEEE 802.3ae, 802.3cc
SFF-8402, SFF-8431, SFF-8432, SFF-8472
CPRI, eCPRI
TCP/IP
Wave Length 1310 nm
Diet 3.3V
Fiber Type 9/125um Single-Mode
Max. cable length 10 km
Connector Duplex LC/UPC
Regulatory Compliance CE, FCC, RoHS
Environment Operating Temperature: 0°C to 70°C (32°F to 158°F)
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
Operating Humidity: 10% to 90% RH, Non-Condensing
Storage Humidity: 5% to 90% RH, Non-Condensing
HARDWARE FEATURES
DDM Yes
QSFP28 MSA Yes
Hot Swappable Yes
Dimensions (L x W x H) 2.24*0.55*0.47 in (57*14*12 mm)
PACKAGE CONTENT
Package Content SM6110-LR
Installation Guide
SFP28 Cable
Data Rate Dual Rate 25.78 Gbps and 10.31 Gbps
