TP-Link Omada SM6110-SR SFP28 | 25G/10G Transceiver on Multimode Fiber

TP-Link Omada SM6110-SR SFP28 | 25G/10G Transceiver on Multimode Fiber

New

The TP-Link Omada SM6110-SR is a transceiver module The SFP28 is designed for high-performance 10G and 25G Ethernet connections over multimode fiber, ensuring reliability and low power consumption. With DDM support for diagnostic monitoring and a hot-swappable design, it offers maximum management flexibility. Thanks to the duplex LC connector and support for IEEE 802.3by/ae standards, it ensures compatibility with major network switches. Transmission ranges reach up to 100 m on OM4 and 300 m on OM3, making it ideal for data centers and modern enterprise networks. CE, FCC, and RoHS certified, it combines security, efficiency, and high stability. Omada

Technical Data Sheet

Reference: SM6110-SR

Brand: OMADA

EAN: 8885020622331

Manufacturer Object ( [id] => 53 [name] => OMADA [description] =>

A key aspect of OMADA is its ability to offer centralised management. This can be done through a dedicated hardware controller, a software controller, or the Omada SDN cloud service, which enables centralised management of networks. The solutions offered are scalable and flexible, making them suitable for both small corporate networks and large multi-site deployments.

OMADA includes wireless solutions with high-performance Wi-Fi access points, ensuring reliable, high-speed coverage. In addition, it offers managed switches and gateway routers with advanced traffic management, security and quality of service (QoS) features.

Security is another strong point of OMADA's solutions, which include advanced features such as firewalls, VPNs and access control to protect corporate networks. In addition, OMADA's cloud platform enables remote configuration and monitoring of networks, offering great flexibility in IT management.

For businesses, OMADA provides a solution that can reduce operating costs through centralised management that simplifies network maintenance. High-quality hardware components ensure stable and reliable performance, while intuitive interfaces and management tools make network administration easier even for non-technical staff.

OMADA's core products include indoor and outdoor access points with advanced technologies such as Wi-Fi 6, managed switches with Layer 2 and Layer 3 capabilities, and security and routing devices for network traffic management and threat protection. OMADA solutions are commonly used in corporate offices to manage internal networks, in schools and universities to provide Wi-Fi connections for students and staff, and in hotels to offer a stable and fast Internet connection to guests.

[short_description] =>

Tp-Link Omada

OMADA is a TP-Link brand of enterprise network management solutions. The OMADA system includes both hardware and software designed to centralise the management of wireless networks, switching and gateways. This approach is designed to improve the control and management of network infrastructures, particularly in enterprise environments.

[id_address] => [date_add] => 2024-06-13 09:45:42 [date_upd] => 2025-08-25 11:30:31 [link_rewrite] => omada [meta_title] => [meta_keywords] => [meta_description] => [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 1 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
FIND INSTALLER


CLEARANCE SALE ×


 CLEARANCE SALE!
Take advantage of our must-see outing offers.
  Discover the promo >>

SM6110-SR | SFP28 MODULE WITH 10G AND 25G ETHERNET CONNECTIONS UP TO 10KM


Made Omada

The TP-Link Omada SM6110-SR SFP28 transceiver is the ideal solution for 10G/25G Ethernet connections over multimode fiber, ensuring maximum reliability, low power consumption, and compatibility with major network standards. With DDM support and a hot-swappable design, it offers advanced monitoring and easy installation, making it perfect for data centers and modern enterprise infrastructures.

Main specifications:

- 10G/25G Multimode SFP28 Transceiver with Duplex LC Connector

- DDM support for real-time diagnostic monitoring

- Hot-Pluggable design for quick installation and replacement

- Power consumption ≤ 1 W with 3.3 V power supply

- Distance up to 300 m on OM3 fiber and 100 m on OM4

Further details

Single-mode SFP+/SFP28 LC:
Featuring a duplex LC interface, this SFP28 module supports 10G and 25G fiber optic connections, offering stable transmission and compatibility with industry standards. Its design allows for simple and secure installation in high-performance network infrastructures.
DDM (Digital Diagnostic Monitoring) :
Includes digital diagnostic monitoring that allows for real-time monitoring of parameters such as signal strength, temperature, and voltage. This feature enables proactive network management, reducing the risk of failure and improving system reliability.
Hot-Pluggable:
Thanks to its hot-swappable design, it can be inserted or replaced without interrupting network service. This feature offers great operational flexibility and minimizes downtime, making it ideal for critical environments such as data centers and corporate networks.

Technical data sheet

Model SM6110-SR
TRANSCRIBER
Standards & Protocols IEEE 802.3ae, 802.3cc
SFF-8402, SFF-8431, SFF-8432, SFF-8472
CPRI, eCPRI
TCP/IP
Wave Length 850 nm
Diet 3.3V
Fiber Type 50/125um or 62.5/125um Multi-mode
Max. cable length 70m (OM3) @25.78Gbps, 100m (OM4) @25.78Gbps, 300m (OM3) @10.31Gbps
Connector Duplex LC/UPC
Regulatory Compliance CE, FCC, RoHS
Environment Operating Temperature: 0°C to 70°C (32°F to 158°F)
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
Operating Humidity: 10% to 90% RH, Non-Condensing
Storage Humidity: 5% to 90% RH, Non-Condensing
HARDWARE FEATURES
DDM Yes
QSFP28 MSA Yes
Hot Swappable Yes
Dimensions (L x W x H) 2.24*0.55*0.47 in (57*14*12 mm)
PACKAGE CONTENT
Package Content SM6110-SR
Installation Guide
SFP28 Cable
Data Rate Dual Rate 25.78 Gbps and 10.31 Gbps
