Bentel 3A 230Vac / 13.8 Vdc power station, microprocessor controlled, in a metal case. Compatible with KYO320 and ABSOLUTA control unit. Restoring bus levels, BPI, Isolator function, Auxiliary power supply. 240 x 348 x 97 mm BXM12 / 30-B Bentel
https://www.setik.biz/en/other-accessories/2883-bentel-security-bxm12-30-b-station-to-power-3a-138-vcc-per-absoluta-and-KYO320-Bentel.html
€230.20
€479.58 -52%
taxes included
discover the available quantity
LO HAI TROVATO A MENO?
Scrivici dove e ti sconteremo la differenza fino a fine mese!
POWER SUPPLY STATION 3A 13.8 VDC FOR KYO320 AND ABSOLUTA CONTROL UNITS - BENTEL
Product details
- Feeding station in metal container - Bentel
- Maximum current: 3A
Microprocessor controlled switching power supply - Input: 230 Vac ± 10% 50/60 Hz
- Vdc output: 13.8
- Stability: ± 1%
- Constant control of switching power supplies with disconnection in case of failure or anomaly
- Constant control of the accumulator with disconnection in case of failure or anomaly
- Check the presence, charge and efficiency of the accumulator
- 3 independent outputs protected by thermal fuse
- Anti-sabotage and tear-proof
- Accumulable accumulator: one of 12 Vdc - 17 Ah
- Input and output bus (regenerated and galvanically isolated)
- It can work in combination with the KST thermal probe kit
- Compatible with KYO320 and ABSOLUTA control unit
- Size: 240 x 348 x 97 mm
Weight: 2.9 kg - High quality
Data sheet
Technical data sheet not available
More details
No additional details availableDownload
No documents available
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification
