Ajax Transmitter Jeweller Wireless Module for Third-Party Wired Sensors

Ajax Transmitter Jeweller Wireless Module for Third-Party Wired Sensors

 

38184.18.NC1 # 38184 | Ajax Transmitter Jeweller is a compact module designed to integrate third-party wired detectors into Ajax security systems, allowing traditional sensors to be transformed into smart wireless devices. It provides encrypted two-way Jeweller radio communication , wired device integration with advanced event management , tamper protection , long-lasting battery power , and full configuration via the Ajax app , offering a reliable and professional solution for upgrading existing systems. Ajax

Technical Data Sheet

DISCOVER ALSO THE AJAX SUPERIOR TRANSMITTER FIBER VERSION 143643.182.NC1

Reference: 38184.18.NC1

Brand: Ajax Systems

EAN: 4823114015489

Disponibilità: 1

Manufacturer Object ( [id] => 31 [name] => Ajax Systems [description] =>

Born in 2011, Ajax System produces alarm and fire systems with JEWELLER radio protocol, a wireless technolog that allows to connect with a few taps the detectors in the mobile app. The Ajax System security system is easy to install in your apartment, home or office. By choosing Ajax System, you get integrated protection that is easy to manage, tamper-resistant and responds instantly to attacks. Ajax  System devices are easy to be installed: just 15 seconds to connect the control panel to the detectors. They can also support third-party surveillance cameras, making Ajax System a singular security center.

[short_description] =>

Ajax SystemsAjax Systems

The alarm systems by Ajax System use a state-of-the-art wireless technology, thus making the devices very reliable and always connected. Ajax System detectors combine the best components with conceptual design.

[id_address] => [date_add] => 2019-01-15 15:51:16 [date_upd] => 2026-03-03 17:54:49 [link_rewrite] => ajax-systems [meta_title] => State-of-the-art alarm and fire systems - Ajax System [meta_keywords] => ajax system,ajax systems,system ajax ,ajax security system,ajax notification system [meta_description] => Alarm systems by Ajax System are innovative, reliable and user-friendly wireless devices. Find them all on Setik.biz [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 1 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
FIND INSTALLER

38184.18.NC1 | WIRELESS MODULE FOR INTEGRATING THIRD-PARTY DEVICES INTO THE AJAX SYSTEM

Ajax

The Ajax Transmitter Jeweller, 38184.18.NC1, is a compact module designed to integrate third-party wired detectors into Ajax security systems, transforming traditional sensors into advanced wireless devices. Thanks to Jeweller radio technology and comprehensive app management, it allows you to monitor events, status, and power supply of the connected device, ensuring reliability, ease of installation, and professional upgrades of existing systems.

DISCOVER ALSO THE AJAX SUPERIOR TRANSMITTER FIBER VERSION 143643.182.NC1

Code 38184.18.NC1 143643.182.NC1
Model Ajax Transmitter Jeweler Ajax Superior Transmitter Fiber
Product type Wireless module for integrating third-party wired sensors Wired module for integrating third-party wired sensors/devices
Technology Wireless Jeweler Fiber Wired
Main difference Transform a traditional wired sensor into a wireless Ajax device Professional wired version: multiple connection types, advanced event management and bus power supply
Connectable devices 1 third-party wired device 1 third-party wired device
Contact / Input Types NC / NO NC, NO, EOL, 2EOL, 3EOL, roller shutter / KeyArm
Power output for external device Yes, it can power external devices 12 V⎓, up to 50 mA
Connection / range Radio Jeweller up to approximately 1,600 m in open field 4-wire fiber line up to 2,000 m
Diet Internal batteries of the module From Fiber Line / Superior Hub Hybrid

Main specifications:

- Two-way, encrypted Jeweler radio communication

- Integration of third-party wired sensors into Ajax systems

- Full event and status management via Ajax app

- Anti-sabotage protection with anti-opening and anti-removal tamper

- Battery powered with long operating time

Further details

✅ Jeweler Communication:
The Ajax Transmitter module uses the encrypted two-way Jeweller radio protocol to ensure stable and secure communication with the Ajax hub, enabling reliable transmission of events from the connected wired sensor, with constant monitoring of the device status and protection against interference and spoofing attempts.
✅ Connecting wired devices :
Designed to integrate third-party wired detectors into Ajax systems, Transmitter allows you to connect traditional sensors and make them part of an advanced wireless ecosystem, maintaining the original functionality of the device and adding advanced notifications, automation scenarios and centralized management via the app.
✅ Anti-sabotage protection :
The device is equipped with integrated security systems such as anti-opening and anti-removal tamper, which send immediate notifications to the hub in case of tampering, ensuring the integrity of the system and a high level of reliability even in professional installations.
✅ Power supply :
Battery-powered, Ajax Transmitter ensures long operational autonomy and continuity of operation without the need for network cabling, making it ideal for rapid installations, retrofitting of existing systems and contexts where installation flexibility is required.

Technical data sheet

38184.18.NC1
Communication
Jeweler communication technology Proprietary wireless communication technology to transmit commands, alarms, and events.
Key features:
  • Two-way communication.
  • Advanced anti-sabotage.
  • Block encryption featuring a dynamic key.
  • Instant notifications.
  • Remote configuration via the Ajax apps.
Radio frequency bands 866.0 - 866.5 MHz
868.0 - 868.6 MHz
868.7 - 869.2 MHz
905.0 - 926.5 MHz
915.85 - 926.5 MHz
921.0 - 922.0 MHz
Depence on the sales reaction
Maximum effective radiated power (ERP) up to 25 mW
Automatic power control to reduce power consumption and radio interference.
Radio signal modulation GFSK
Radio signal range Up to 1,600 m
Between the detector and a hub (or radio signal range extender) in an open space.
Encrypted radio communication All the data stored and transmitted are protected by block encryption featuring a dynamic key.
Frequency hopping To prevent radio interference and jamming
Wired devices connection
Supported configurations Transmitter Jeweler has two pairs of terminal inputs for tamper and alarm sensor connection. Alarm and tamper inputs can be used to connect a wired device using the AATT (Alarm Alarm Tamper Tamper) scheme
Terminals for wired device connection
  • “+ –” — 3.3 V⎓ power supply output for connecting a wired device
  • ALARM — inputs for connecting a wired device
  • TAMP — inputs for connecting a tamper of a wired device
Third-party device contact states NO, NC
Tamper contact states NO, NC
Cable length up to 130 m
When using 24 AWG twisted pair cable
Operation mode pulse, bistable
Sensor modes Notify of alarms, Switch arming modes
Event types 14 event types of wired devices
  • Intrusion
  • Fire
  • Auxiliary alarm
  • Panic button
  • Gas alarm
  • Malfunction
  • Leakage
  • Glass break
  • High temperatures
  • Low temperatures
  • Masking
  • Duress code (opening)
  • Vibration (seismic sensor)
  • Custom
Adjusted by a PRO or a user with admin rights in the Ajax app.
Recommendations Transmitter Jeweler should be installed inside the wired detector enclosure. The module requires a minimum space with dimensions of 110 × 41 × 24 mm. If it is not possible to install Transmitter Jeweler within the detector's enclosure, any available radiotransparent casing can be used.
Sabotage protection
Protection against spoofing integration module authentication
Accelerometer alert when the integration module is moved
Tamper alarm terminals Terminals for connecting to a wired device tamper (if applicable).
Communication loss detection after 36 s
Detection time depends on the Jeweler or Jeweller/Fibra settings
Power supply
Battery 3 × CR123A
Pre-installed. Battery life depends on the power consumption of a connected wired device
Output to the connected wired device 3.3 V⎓, up to 125 mA
One power supply line from Transmitter Jeweller
Enclosure
Color Black
Dimension 100 × 39 × 22 mm
Weight 74 g
Operating temperature range from −25 °C to +50 °C
Operating humidity up to 75%
Electric shock protection Class III
Complete set Transmitter Jeweler
3 × CR123A battery (pre-installed)
Installation kit
Quick start guide
Warranty 24 months
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
