HYU-1041-3TB 16-Channel IP NVR with 4K HDMI and 3TB HDD | Professional Video Surveillance

HYU-1041-3TB 16-Channel IP NVR with 4K HDMI and 3TB HDD | Professional Video Surveillance
New

HYU-1041-3TB - The NVR is a 16-channel IP video recorder with support for H.265+/H.265 compression and resolution up to 8MP , ideal for advanced video surveillance systems. It offers 1080P VGA and 4K HDMI video outputs, smooth decoding up to 30 fps, and two-way audio via RCA. It integrates a 3TB hard drive dedicated to security, 4-channel AI motion detection 2.0 , and VCA from IP cameras. Compatible with advanced network protocols, it supports up to 32 remote connections with stable and secure access. Hyundai

Technical Data Sheet

Reference: HYU-1041-3TB

Brand: Hyundai Security

Manufacturer Object ( [id] => 30 [name] => Hyundai Security [description] =>

Born in Corea, Hyundai Corporation is a leader in the creation of digital products and distinguishes itself for the wide range of industrial, electrical and electronic products. Hyundai Corporation has entered the CCTV field by developing and projecting security devices such as high level recorders and cameras, both for their technology and for their design. The main aim of the Corean company is to guarantee the protection and safety of people inside their houses, offices or means of transport.

All Hyundai video surveillance systems are appreciated and recommended by industry professionals especially because the majority of the range is based on Hikvision technology, which is why they are fully compatible.

The official distributors of Hyundai Security are few because there are few realities, like Setik, authorized to distribute it. At the basis of this policy is the will to protect and safeguard the brand, thus avoiding aggressive channel choices.

Hyundai Security

[short_description] =>

Videosorveglianza Hyundai

Hyundai Security products for the protection and safety, to be installed in your home, office or means of transport.

[id_address] => [date_add] => 2018-10-29 15:00:38 [date_upd] => 2021-06-18 12:43:04 [link_rewrite] => hyundai-security [meta_title] => Hyundai Security [meta_keywords] => Hyundai Recorder,Hyundai Security CCTV ,Hyundai Security,Hyundai CCTV Cameras [meta_description] => Hyundai Corporation projects and develops seucrity CCTV systems by offering innovative and advanced devices, both for their technology and their design [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 1 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
FIND INSTALLER


CLEARANCE SALE ×


 CLEARANCE SALE!
Take advantage of our must-see outing offers.
  Discover the promo >>

HYU-1041-3TB | 16-CHANNEL IP NVR RECORDER - MAXIMUM RESOLUTION 8MP - 1 x 3TB HDD INCLUDED


Dahua

The HYU-1041-3TB NVR is a 16-channel IP network video recorder designed for advanced surveillance systems. It offers H.265+/H.265 compression for optimized storage management, supports resolutions up to 8MP, and ensures excellent video quality with 1080P VGA and 4K HDMI outputs. The system includes AI-based intelligent motion detection and a 3TB HDD for continuous and reliable storage.

Main specifications:

- Number of channels: 16 IP camera inputs

- IP Technology: Compatible with H.265+, H.265, H.264+ and H.264

- Resolution: Recording up to 8MP, smooth decoding up to 30fps

- Video outputs: VGA 1080P + HDMI 4K for high definition viewing

- Two-way audio: 1 input and 1 RCA output

- Motion Detection 2.0: AI for 4-channel human and vehicle detection

- HDD included: 3TB disk dedicated to video surveillance, expandable up to 8TB

Further details

Number of channels:
It supports 16 IP camera inputs , allowing centralized management of a large security system.
IP Technology :
Compatible with H.265+, H.265, H.264+ and H.264, it offers efficient compression to save bandwidth and storage space, without compromising image quality .
Resolution:
Supports recording up to 8MP , with smooth 30fps decoding on 1 channel 8MP, 3 channels 4MP or 6 channels 1080P. Ideal for high-definition images even in complex scenarios .
HDMI 4K and VGA 1080P outputs :
Equipped with simultaneous video outputs , it allows high-definition viewing on multiple monitors, improving management and operational efficiency.
Two-way audio:
It has 1 RCA input and 1 RCA output , offering the possibility of remote communication or direct environmental interaction via microphone and speaker.
Motion Detection 2.0:
On up to 4 channels, it uses deep learning to distinguish between people and vehicles, reducing false alarms caused by lights, leaves or other disturbing objects.
Includes 1 x 3TB HDD :
Supplied with a dedicated hard drive for video surveillance , expandable up to 8TB via SATA port. It ensures continuous and reliable storage over time.

Technical data sheet

HYU-1041-3TB
Specifications
16 IP camera inputs
H.265+, H.265, H.264+ and H.264 compression formats
Incoming bandwidth: 160 Mbps
Outgoing bandwidth: 80 Mbps
Simultaneous VGA 1080P and HDMI 4K video outputs
Two-way audio: 1 RCA input / 1 RCA output
Recording Resolution: 8MP, 6MP, 5MP, 4MP, 4MP, 3MP, 1080P, UXGA, 720P, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF
Decoding capability: 1 channel 8MP (30 fps), 3 channels 4MP (30 fps), 6 channels 1080P (30 fps)
16-channel synchronized playback
Internal capacity for 1 SATA HDD up to 6TB ( includes a special 3TB HDD for video surveillance )
Motion Detection 2.0 on up to 4 channels: Deep learning-based Motion Detection 2.0 can classify people and vehicles and minimize false alarms caused by lights or objects such as leaves.
Smart search
Self-adaptive RJ45 Ethernet (10/100/1000M) network interface
Network protocols: TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Up to 32 remote connections
Connections: 2 USB 2.0
Power supply: 12V DC, 1.5A
Power consumption: ≤10W (without HDD)
Operating temperature: -10°C ~ +55°C
Relative humidity: 10~90%.
Dimensions: 320 (W) x 48 (H) x 320 mm
Weight: ≤1 kg
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
