ONVIF® PoE 2MP Pinhole Covert WizMind Mini IP Camera - Dahua

ONVIF® PoE 2MP Pinhole Covert WizMind Mini IP Camera - Dahua
-58% New

IPC-HUM8241E-E1 - 2MP Mini Surveillance IP Camera , ONVIF PoE , Compression up to H.265+, Triple Stream , Intelligent Detection (IVS) and Facial Detection, Smart Search , ROI , Day/Night, BLC, HLC, WDR 120dB, ROI, AUDIO 1in&out defog and Alarm 2 in&out. 512GB MicroSD slot (not included). Dahua



Reference: IPC-HUM8241E-E1

Brand: Dahua

EAN: 6939554941382

Manufacturer Object ( [id] => 13 [name] => Dahua [description] =>

The Asian Company, born in 2001, is famous because of the excellent quality of its product in terms of performances and potential.

The range of products made by Dahua includes not only classic CCTV systems but also more complex and articulate systems: not only video surveillance, indeed, but also access control, video intercoms, thermal cameras and much more.

The reliability, the cutting-edge technologies and the competitive prices offered by Dahua are only some of the reasons why Setik has always chosen to distribute this brand. Dahua has been for years a reference point in the international CCTV market, due to the huge investments dedicated every year to Research and Development. Numbers are clear: since 2016, Dahua has registered more than 800 patents with its own brand.

The Dahua-branded products sold by Setik Srl could eventually be delivered as OEM: this means that the items are absolutely original and made by Dahua, but characterized by a different aesthetic look reserved for the online market (generally as far as the logo and the package are regarded).

This has no effects on the warranty and on the technical specifications nor even on the possible updates and functionalities, because the products are authentic Dahua’s ones.

[short_description] =>

Videosorveglianza Dahua

Zhejiang Dahua Technology Co., Ltd. is one of the leading solution providers in video surveillance industry, with more than 13,000 employees and 35 active branches all over the world.

[id_address] => [date_add] => 2012-07-14 17:53:54 [date_upd] => 2025-03-19 12:15:55 [link_rewrite] => dahua [meta_title] => Best Dahua Products: DVR, HCVR,NVR, IPC,SD,PTZ,HDCVI, [meta_keywords] => dahua, dahuatech, dahua distribution, dahua national supplier [meta_description] => Dahua, TVCC manufacturer, IP, Analogue and SDI,HD-CVI [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 1 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
FIND INSTALLER


CLEARANCE SALE ×


 CLEARANCE SALE!
Take advantage of our must-see outing offers.
  Discover the promo >>

MINI IP CAMERA ONVIF® POE DAHUA 2 MEGAPIXEL - VIDEO ANALYSIS - FACE DETECTION - AUDIO and ALARM

Prodotto Marca Dahua
Dahua ONVIF® PoE Mini IP Camera
2 Megapixel Resolution - Face Detection and Perimeter Protection (IVS)
- Day/Night - ROI / WDR 120 dB / BLC / HLC / Defog - Audio (In/Out) - Alarm (In/Out)

Product details

IPC-HUM8241E-E1
  • Dahua ONVIF® PoE Mini IP Camera
  • Triple Stream
  • Video comprehension up to H.265+
  • 2MP resolution
  • Day/Night(Electronic) BLC, HLC, WDR real 120dB, Defog
  • Video Analysis: Line Crossing, Intrusion
  • Face Detection
  • Cloud P2P with Easy4ip application
  • Audio: 1 input / 1 output
  • Alarm: 2 inputs / 2 inputs
  • No optics - Requires mini camera sensor unit
  • Micro SD Slot (Maximum 512GB - Not Included )
  • Size: 110mm × 83mm × 24mm

Technical data sheet


Model IPC-HUM8241E-E1
Room
Image Sensor 1/2.7”
Max. Resolution 1920 (H) × 1080 (V)
ROM / RAM 256MB / 1GB
Scanning System Progressive
Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s
Min. Illumination 0.005 Lux@F2.0 (Color,30 IRE)
0.0005 Lux@F2.0 (B/W,30 IRE)
Y/N Ratio >56dB
Intelligence
IVS (Perimeter Protection) Tripwire, intrusion, fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection, people gathering, and parking detection
Smart Object Detection Smart abandoned object; smart missing object
AcuPick Uses deep learning algorithms and works with back-end devices to accurately match targets, such as people, animals and motor vehicles, and search through live and recorded videos to quickly locate targets.
Face detection Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attribute extraction including 6 attributes (gender, age, glasses, expressions, mask and beard) and 8 expressions (anger, calm, happiness, sadness, disgust, surprise, confusion and fear); face snapshot set as face or one-inch photo; 3 snapshot strategies (real-time snapshot, optimization snapshot, and quality priority); face angle filter; optimization time setting
People Counting Tripwire people counting and people counting in area; generating and exporting reports (day/month/year); queue management; 4 rules can be set for tripwire, people counting in area and queue management.
Privacy Protection Mosaics can be automatically placed over the face or body of a person to protect their privacy
SmartSearch Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
Video(working together with lens unit)
Video Compression

H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)

AI Codec

AI H.265; AI H.264

Video Frame Rate Main stream: 1920 × 1080@(1–50/60 fps)
Sub stream: 1920 × 1080@(1–25/30 fps)
Third stream: 1920 × 1080 @25/30 fps
*High frame rate of main stream is supported under monitoring mode only
Note: AI/WDR cannot be enabled at the same time as high frame rate.
Stream Capability 3 streams
Resolution 1080p (1920 × 1080); 1.3M (1280×960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bitrate Control VBR;CBR;ABR
Video Bitrate H.264: 3 kbps–8192 kbps;
H.265: 3kbps–8192kbps
Day/Night Color/B/W
BLC Yes
HLC Yes
WDR 120dB
Self-adaptation scenes Yes
White Balance Car; natural; street lamp; outdoor; manual; regional custom
Gain Control Manual; car
Noise Reduction 3D NR
Motion Detection OFF/ON (4 areas, rectangular)
Region of Interest (RoI) Yes (4 areas)
Defog Yes
Image Rotation 0°/90°/180°/270° (support 90°/270° with 1080p resolution and lower)
Mirror Yes
Privacy Masking 4 areas
Audio
Audio Compression

G.711a; G.711Mu; PCM; G.726; G.723

Alarm
Alarm

No SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, motion detection, video tampering, tripwire, intrusion, fast moving, missing object, abandoned object, parking detection, loitering detection, people gathering; scene changing, audio detection, voltage detection, external alarm, face detection, and security exception

Network
Ethernet

RJ-45 (10/100Base-T)

SDK and API

Yes

Network Protocol

IPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P; Bonjour; Auto Registration

Interoperability

ONVIF® (Profile S/Profile G/Profile T); CGI; P2P; Milestones; Genetec

User/Host 20 (Total bandwidth: 64M)
Storage FTP; SFTP; Micro SD card (support max. 512G); NAS
Browser IE: IE8, IE9, and IE11 Chrome Firefox
Management Software Smart PSS; DSS; DMSS; DoLynk Care
Mobile Client IOS; Android
Cyber Security Digest;WSSE;Account lockout;Security logs;IP/MAC filtering;Generation and importing of X.509 certification;syslog;HTTPS;802.1x;Trusted boot;Trusted execution;Trusted upgrade;Session security;Security warning
Certifications
Certifications

CE-LVD:EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU;

Port
Audio Input 1 channel (3.5mm JACK port)
Audio Output 1 channel (3.5mm JACK port)
Alarm Input 2 channels in: 5 mA 3V–5V DC
AlarmOutput 2 channels out: 1,000 mA 30V DC/500mA 50V DC
Power
Power Supply 12V DC/PoE(802.3af)
Dual Power Backup When the power adapter and PoE provide power at the same time, disconnect one of them. The device will continue to work, but will not restart.
Power Consumption Basic: 4W (12VDC); 5.6W (PoE);
Max.: 5.7W (12VDC); 6.7 W (PoE) (High frame rate + Intelligence on + WDR)
Environmental
Operating Temperature –40°C to +60°C (–40°F to 140°F)
Operating Humidity ≤95%
Storage Temperature –40°C to +60°C (–40°F to 140°F)
Storage Humidity ≤95% (RH) , non-condensing
Construction
Casing Metal
Dimensions 110 mm × 83 mm × 24 mm (4.33" × 3.27" × 0.94")
Net Weight 210g (0.5lb)
Gross Weight 376g (0.8lb)

Further details

PoE Power Supply The advantage of a PoE camera is clear, it can be powered with the same cable with which it communicates without carrying additional power cables and without having to install a separate power system, a PoE camera guarantees constant voltages and simple installation.
Standard ONVIF® Onvif, the absolute standard for IP cameras. Being Onvif guarantees compatibility with any modern recording system. NOT being Onvif, means having a camera that is an end in itself and can never be used together with recording systems.
Risoluzione 2Mpx This camera has a resolution of 2Megapixel : 2 MP

Codifica video Smart H.265+

Smart H.265+

Smart H.265+ is the optimized implementation of H.265 codec that uses scene-adaptive coding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure and intelligent noise reduction to deliver high-quality video without straining the network.

Smart H.265+ greatly reduces bit rate and storage requirements compared to standard H.265 compression.

Video compressione Smart H.265+

Main stream: 1920 × 1080@(1–50/60 fps)
Sub Stream: 1920 × 1080@(1–25/30 fps)
Third Stream: 1920 × 1080 @25/30 fps
Full HD

Cloud function with Easy4IP

This camera features advanced intelligent functions :

- Face Detection

Rilevamento Volto Video Analisi

This camera provides VIDEO ANALYSIS (SMART DETECTION) functions:
- Line crossing recognition
- Intrusion recognition

Line Crossing Recognition

ULTRA WDR up to 120dB
WDR (Wide Dynamic Range): This is the professional solution when you need to work in high light/shadow contrast conditions. It is essential when shooting from inside to outside, license plates, shadowed areas or any situation where there is no homogeneity of light.
Day/Night Function Icon Day/Night: allows you to adapt the lens to night/day vision, and the relative automatic management of the IR Illuminator, when present.
Day/Night Function Example

BLC (Back Light Compensation): is one of the 3 possible steps in the management of images with contrast, typical situations are: entrances or exits from parking lots, license plates, particular lights, entrances with shots from the inside towards the outside, etc. Light compensation is one of the most complex operations possible, the BLC function allows a fair adaptation to these situations.

Ingresso / Uscita Audio

Ingresso / Uscita Allarme

This camera features:

1 input + 1 audio output

2 input + 2 alarm output

MicroSD Recording

Possibility to insert Micro SD up to a maximum of 512Gb (Not Included)

12VDC_Power

12V DC power supply NOT included!

Italian Guarantee Icon This product is covered by a 24 month warranty.

Download

Download the Brochure in English
IPC-HUM8441-E1 DIMENSIONS
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
