Dahua Access Control: Standalone biometric terminal with integrated RFID reader of MIFARE 13.56MHZ and NFC cards . Touch keyboard and 2.4 "LCD display, 3000 fingerprints, 30.000 cards / users, 150.000 events. Communication via Wiegand, RS485, Supports P2P devices, 2 inputs + 1 alarm output. Equipped with USB port, IP65 . ASI2212H-W Dahua Technology
https://www.setik.biz/en/standalone-controller/7930-dahua-asi2212h-w-biometric-access-control-rfid-mifare-usb-ip65-dahua.html
€243.39
€579.50 -58%
taxes included
discover the available quantity
LO HAI TROVATO A MENO?
Scrivici dove e ti sconteremo la differenza fino a fine mese!
BIOMETRIC TERMINAL WITH RFID PROXIMITY READER FOR MIFARE & NFC CARDS - DAHUA
Product details
- Biometric terminal - Dahua Security
- Useful for access control
- Touchscreen keyboard
- 2.4 "TFT display
- Communication: Wiegand, RS485 to the reader
- Identification through RFID Cards, Code, fingerprint or combination
- Compatible with Mifare 13.56MHz RFID cards (Range 0-5 cm)
- Capacity up to 30,000 users, up to 3000 fingerprints, up to 30,000 cards, up to 30,000 passwords, up to 150,000 events
- Support adding P2P devices
- 1x USB 2.0 port
- Power supply: 12 VDC, 1A
- Size: 183mm * 80mm * 25.5mm
Data sheet
| Model | ASI2212H-W |
| System | |
| Main processor | High-performance embedded processor |
| Network Protocol | IPv4; TCP; UDP; P2P |
| Basic | |
| Display Screen | 2.4 "LCD |
| Screen Type | LCD |
| Resolution | 240 (H) × 320 (V) |
| Voice Prompt | Yes |
| Buzzer | Yes |
| Casing | PC + ABS |
| Function | |
| Unlock Mode | Card / Remote / Password / Fingerprint unlock and unlock through their combinations |
| Card Type | IC or ID card |
| Period List | 128 |
| Holiday Period | 128 |
| Network Update | Yes |
| First User Unlock | Yes |
| Remote Verification | Yes |
| Restricted List / Trusted List | Yes |
| Wifi | Yes |
| Peripheral Card Reader | 1 × RS-485 card reader 1 × Wiegand card reader |
| Multi-user Authentication | Yes |
| Multi-factor Authentication | Yes |
| Web Configuration | Yes |
| Auto Regolation | Yes |
| Performance | |
| Card Reading Distance | 0-5 cm (0 "to 1.97") |
| Fingerprint Sensor Type | Capacitive fingerprint scanner |
| Fingerprint Comparison Time | 1 s |
| User | |
| User (Card) Type | General user, VIP user, patrol user, guest user, blocklist user and others |
| Capacity | |
| User Capacity | 30,000 users |
| Fingerprint Capacity | 3,000 |
| Card Capacity | 30,000 |
| Password Capacity | 30,000 |
| Record Capacity | 150,000 unlock records |
| Port | |
| RS-485 | 1 |
| RS-232 | 1 |
| Wiegand | 1-ch input / output |
| USB | 1 × USB2.0 port |
| Network Port | 1 × RJ-45, 100 Mbps |
| Alarm Input | 2 (digital quantity) |
| Alarm Output | 1 (relay) |
| Alarm Linkage | Yes |
| Doorbell | 1 |
| Exit Button | 1 |
| Door Status Detection | 1 |
| Lock Control | 1 |
| Alarm | |
| Anti-pass Back | 1 |
| Tamper Alarm | 1 |
| Duress Alarm | 1 |
| Door Sensor Timeout | 1 |
| Intrusion | 1 |
| Illegal Card Exceeding Threshold | 1 |
| Duress Fingerprint | 1 |
| General | |
| Power Adapter | Optional |
| Power Supply | 12 V DC, 1 A |
| Protection | IP65 (silicone sealant is needed, see the quick start guide) |
| Power Consumption | ≤ 12 W |
| Product Dimensions | 183mm × 80mm × 25.5mm (7.20 "× 3.15" × 1.00 ") (H × W × D) |
| Packaging Dimensions | 248 mm × 143 mm × 66 mm (9.76 "× 5.63" × 2.60 ") (H × W × D, 1 in an inner carton) |
| Operating Temperature | –30 ° C to +65 ° C (–22 ° F to +149 ° F) |
| Operating Humidity | 10% –95% (RH), no condensing |
| Operating Environment | Indoor; outdoor |
| Net Weight | 264 g (0.58 lb) |
| Gross Weight | 464 g (1.02 lb) |
| Accessory | Bracket (included) |
| Installation | Surface mount |
| Certifications | THERE IS; FCC |
Further details
 | This terminal is STANDALONE . This means that it is autonomous, able to manage functions without having to integrate other devices. |
 | Equipped with 2.4 "LCD Display (320x240) |
| Autonomous biometric terminal with touch keyboard and identification by: - Combination - Mifare card (13.56MHz) |
  | Communication via TCP / IP RJ45 (100Mbps), RS485 or Wiegand |
| Up to 30,000 users, |
 | Dahua Smart PSS software
|
 | Equipped with USB port |
 | This product is covered by a 24 month warranty. |
