KTX01S | VIDEO DOOR PHONE KIT

Dahua

The Dahua KTX01S Wi-Fi video intercom with 2-wire technology guarantees advanced security and maximum convenience for every home, with a 7" touchscreen monitor, app management and remote door opening. The complete kit includes an internal monitor, an outdoor station with a 2MP camera and a compact controller, ideal for simple and reliable installations.

Main specifications:

- 7” high definition TFT touch screen

- Two-way audio communication via app

- 2MP outdoor camera with night vision

- IP65/IK07 tamper-proof for outdoor use

- Notifications and video recordings directly on the app

- Simple and safe 2-wire installation

Further details

DHI-VTH5123H-W - 2 Wire Wi-Fi Indoor Monitor:
  • 7" HD Touch Display : 7” TFT capacitive screen with 1024x600 resolution for sharp images and immediate touch response.
  • Advanced Two-Way Audio : Half-duplex communication with VTO and full-duplex via mobile app, with digital noise reduction and echo cancellation.
  • Video and Photo Recording : Supports recording and snapshots on microSD up to 64GB, ideal for monitoring entrances even when away.
  • Alarm Inputs and Outputs : 6 alarm inputs, 1 output, complete management of external sensors.
  • Built-in Wi-Fi : Stable 2.4GHz wireless connection with support for b/g/n protocols.
  • Do Not Disturb Mode : Customize DND schedules to avoid unwanted interruptions.
  • Low Power Consumption : Only 2.5W in standby, maximum 10W in operation.
DHI-VTO2003F - 2-Wire External Video Intercom Station :
  • 2MP Wide Angle Camera : 1/2.8” CMOS sensor with H110°/V60° viewing angle, high image quality.
  • Automatic Night Vision : Built-in IR illumination for optimal visibility even at night.
  • Tamper-proof and Double Security : Anti-tear alarm, main and secondary lock management.
  • IP65/IK07 Protection : Water, dust and vandal resistant, perfect for outdoor use.
  • Recordable Video Messages : Ability to leave video messages in case of unanswered calls.
  • Power supply via 2-wire controller : Easy installation with reduced wiring.
VTNC1003C - 2 Wire Controller :
  • Easy Signal Management : Converts signal from IP to 2-wire while maintaining stable video/audio quality.
  • Compact and Lightweight : Small size (65x46x23 mm) for discreet installation.
  • Low Power Consumption : Maximum consumption 3.5W with 48VDC power supply.
  • CE and FCC Certifications : Complies with international safety standards.
  • Extended Operating Temperature : Operates from -10°C to +55°C ensuring stability even in adverse weather conditions.

Technical data sheet

KIT: KTX01S

VTO2003F

System

Main Processor

Embedded Processor

Button Type

Mechanical

Basic

Room

1/2.8" 2 MP CMOS HDR Camera

Field of View

H: 110°; V: 60°

WDR

DWDR

Noise Reduction

3D NR

Video Resolution

P: 960 (H) × 576 (V)
N: 960 (H) × 480 (V)

Video Frame Rate

P: 25 fps
N: 30 fps

Light Compensation

Auto IR

Day/Night

Auto(ICR)/Color/B/W

Audio Input

1

Audio Output

5

Wi-Fi

Yes

Wireless Standard

IEEE802.11b/802.11g/802.11n

Wireless Frequency Range

2.4 GHz

Storage

Micro SD card (up to 64 GB)

Port

RS-485

1

Alarm Input

6

Alarm Output

1

Power Output

1 (12 V, 200 mA)

Door Bell

Yes (use the alarm input port)

Performance

Casing Material

PC + ABS

General

Appearance Color

White

Power Supply

2-wire controller

Installation

Surface Mount

Certifications

CE; FCC

Product Dimensions

130 mm × 189 mm × 23.9 mm (5.12" × 7.44" × 0.94")

Operating Temperature

–10 °C to +55°C (14 °F to +131 °F)

Operating Humidity

10%–95% (RH)

Operating Altitude

0 m–3000 m (0 ft – 4265.09 ft)

Power Consumption

≤ 2.5W(standby), ≤10W(working)

Gross Weight

0.633 kg (1.40 lb)

Storage Temperature

–40 °C to +70°C (–40 °F to +158 °F)

Storage Humidity

95% (RH), non-condensing

VTNC1003C

Performance

Casing Material

PC + ABS

General

Appearance Color

White

Power Supply

48 VDC

Certifications

CE; FCC

Accessory

Included: Line termination terminal

Product Dimensions

65.2 mm × 46.2 mm × 23.2 mm (2.57" × 1.82" × 0.91")

Operating Temperature

–10 °C to +55°C (14 °F to +131 °F)

Operating Humidity

10%–95% (RH)

Operating Altitude

0 m–3000 m (0 ft – 4265.09 ft)

Power Consumption

3.5 W

Gross Weight

0.13 kg (0.29 lb)
