KTP05(F) Flush-Mounted IP Video Intercom Kit with 7" Touch Monitor, Wi-Fi, MIFARE Reader, and 2MP Camera - Dahua

KTP05(F) Flush-Mounted IP Video Intercom Kit with 7" Touch Monitor, Wi-Fi, MIFARE Reader, and 2MP Camera - Dahua

 
-56%

KTP05(F) - is a flush-mounted IP video intercom kit designed for villas and homes, consisting of an external unit with 2 MP HD camera , integrated MIFARE reader , mechanical keyboard and 7" capacitive touch monitor with Wi-Fi . It supports opening via card, password and remote app , management of up to 5,000 users and 10,000 cards , H.265/H.264 compression and PoE power supply. Thanks to IP65 and IK08 protection, ONVIF compatibility and the control of 2 locks , it guarantees a reliable, elegant and complete system for residential access control. Dahua

Technical Data Sheet

Reference: KTP05(F)

Brand: Dahua

Manufacturer Object ( [id] => 13 [name] => Dahua [description] =>

The Asian Company, born in 2001, is famous because of the excellent quality of its product in terms of performances and potential.

The range of products made by Dahua includes not only classic CCTV systems but also more complex and articulate systems: not only video surveillance, indeed, but also access control, video intercoms, thermal cameras and much more.

The reliability, the cutting-edge technologies and the competitive prices offered by Dahua are only some of the reasons why Setik has always chosen to distribute this brand. Dahua has been for years a reference point in the international CCTV market, due to the huge investments dedicated every year to Research and Development. Numbers are clear: since 2016, Dahua has registered more than 800 patents with its own brand.

The Dahua-branded products sold by Setik Srl could eventually be delivered as OEM: this means that the items are absolutely original and made by Dahua, but characterized by a different aesthetic look reserved for the online market (generally as far as the logo and the package are regarded).

This has no effects on the warranty and on the technical specifications nor even on the possible updates and functionalities, because the products are authentic Dahua’s ones.

[short_description] =>

Videosorveglianza Dahua

Zhejiang Dahua Technology Co., Ltd. is one of the leading solution providers in video surveillance industry, with more than 13,000 employees and 35 active branches all over the world.

[id_address] => [date_add] => 2012-07-14 17:53:54 [date_upd] => 2026-02-19 16:06:32 [link_rewrite] => dahua [meta_title] => Best Dahua Products: DVR, HCVR,NVR, IPC,SD,PTZ,HDCVI, [meta_keywords] => dahua, dahuatech, dahua distribution, dahua national supplier [meta_description] => Dahua, TVCC manufacturer, IP, Analogue and SDI,HD-CVI [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 1 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
FIND INSTALLER


KTP05(F) | DAHUA VIDEO INTERCOM KIT - IP


Dahua

The Dahua KTP05(F) is a flush-mounted IP video intercom kit designed for villas and homes, consisting of an external unit with 2 MP HD camera , MIFARE reader , mechanical keypad and 7" capacitive touch monitor with Wi-Fi . It supports opening via card, password and remote app , management of up to 5,000 users and 10,000 cards , two-way audio communication, H.265/H.264 compression and PoE power supply. IP65 and IK08 protection, ONVIF compatibility and the control of 2 locks make it a complete, safe and elegant solution for residential access control.

Main specifications:

  • Camera: 2 MP HD 140° wide angle
  • Monitor: 7" capacitive touch display with Wi-Fi
  • Access: MIFARE card, password and remote app
  • Capacity: Up to 5,000 users and 10,000 cards
  • Compression: H.265 / H.264
  • Audio: Two-way communication
  • Power supply: PoE
  • Installation: Flush Mount
  • Protection: IP65 and IK08
  • Compatibility: ONVIF and Wiegand interface

Further details

  • PoE IP outdoor station
  • 2MP 1/2.9" CMOS sensor
  • Flush or surface mounting
  • Two-way audio
  • 1in/1out alarm
  • IP65 protection ideal for outdoor use
  • IK08 impact protection, ideal against vandalism
  • Authentication via Mifare cards (integrated reader)
  • Mechanical buttons
  • RJ-485 port
  • Product made of aluminum alloy
  • Supports PoE power supply
  • Dimensions: 200mm×98mm×35.4mm
  • Net weight of the item: 692 g
  • Quality product
  • 24 month warranty
  • 7-inch capacitive touchscreen monitor
  • Intercom with other compatible internal stations
  • 7" capacitive touchscreen color display (1024x600 pixel resolution)
  • Alarm: 6 inputs + 1 output
  • Two-Way Audio: Microphone + Speaker
  • Alarm integration (6 inputs and 1 output)
  • Doorbell
  • 100M Ethernet
  • Power supply: 12 VDC 1A;
  • Standard PoE (36–57V, 0.35A)
  • Image acquisition and recording (SD card required)
  • White color
  • Installation: Built-in
  • Dimensions: 189.6mm × 134.6mm × 26.0mm
  • Item net weight: 0.34 kg
  • 24 month warranty

✅ PFS3006-4ET-36 :
  • 6-port Fast Ethernet switch (4 PoE + 2 uplink).
  • 4 x IEEE 802.3af/at PoE ports (up to 30W/port).
  • Total PoE budget 36W.
  • PoE up to 250m (Extend mode).
  • PoE Watchdog function.
  • Power supply 100–240 VAC.
  • Operating temperature -10 °C ÷ +55 °C.

Technical data sheet

Model KTP05(S)
System (VTO)
Main Processor Embedded Processor
Operating System Embedded Linux OS
Button Type Mechanical
Interoperability ONVIF; CGI
Network Protocol SIP; P2P; IPv4; DNS; RTSP; RTP; TCP; UDP
Basic (VTO)
Room 1/2.9" 2 MP CMOS
Field of View H: 140°, V: 80°, D: 160°
WDR 120 dB
Noise Reduction 3D NR
Video Compression H.264; H.265
Video Resolution Main stream: 720p, WVGA, D1, CIF
Sub stream: 1080p, WVGA, D1, QVGA, CIF
Video Frame Rate 25 fps;
Light Compensation Auto white light
Day/Night Color/B/W
Audio Compression G.711a; G.711u; PCM
Audio Input 1
Audio Output Built-in speaker
Audio Mode Two-way audio
Audio Enhancement Echo suppression/digital noise reduction
Audio Bit Rate 16 KHz, 16 bit
Function(VTO)
Communication Mode Digital 2-wire
Unlock Mode Card; password; remote unlock
Card Type Mifare card
Auto Snapshot Yes (SD card is inserted in the indoor monitor or door station)
Leave Videos Yes (SD card is inserted in the indoor monitor or door station)
Storage Supports Micro SD card (up to 256 GB)
Web Configuration Yes
Performance (VTO)
Card Reading Distance 0 cm–3 cm (0"–1.18")
Casing Material Aluminum alloy
Capacity (VTO)
Card Capacity 10000
Port(VTO)
RS-485 1
Wiegand 1
Alarm Input 1
Alarm Output 1
Power Output 1 port, 12 V and 600 mA
Exit Button 1
Door Status Detection 1
Lock Control 1
Network Port 1 × RJ-45 port, 10/100 Mbps network port
Alarm (VTO)
Tamper Alarm Yes
General (VTO)
Appearance Color Silver
Power Supply 48VDC, 0.4A; PoE (802.3af/at)
Power Adapter Optional
Installation Surface
Certifications THERE IS
Product Dimensions 200.0 mm × 98.0 mm × 35.4 mm (7.87" × 3.86" × 1.39")
Protection IK08, IP65 (Silicone sealant is needed, see the quick start guide)
Operating Temperature –40 °C to +60 °C (–40 °F to +140°F)
Operating Humidity 10%–95% (RH), non-condensing
Operating Altitude Beneath 3000 m (9842.52 ft)
Operating Environment Outdoor
Power Consumption ≤ 5 W (standby), ≤ 7 W (working)
Gross Weight 692 g (1.53 lb)
Storage Humidity 30%–75% (RH)
Storage Temperature 0 °C to +40 °C (+32 °F to +104 °F)
System(VTH)
Main Processor Embedded Processor
Operating System Embedded Linux OS
Network Protocol RTSP; DNS; RTP; SIP; SSH
Basic(VTH)
Screen Type Capacitive Touchscreen
Display Screen 7" TFT
Screen Resolution 1024 (H) × 600 (V)
Audio Compression G.711a; G.711u; PCM
Audio Input 1
Audio Output Built-in speaker
Audio Mode Two-way audio
Audio Enhancement Echo suppression
Audio Bit Rate 16 KHz; 16 bit
Function(VTH)
Communication Mode Full digital
Information Release Receive and view text information released by the management center
Leave Videos Yes (SD card inserted in VTH is needed)
Wi-Fi Yes
Wireless Standard IEEE802.11b/802.11g/802.11n
Wireless Frequency Range 2.4 GHz
Max. Transmission Power ≤[email protected]
Wireless Security Encryption WPA/WPA2;WPA-PSK/WPA2-PSK
DND Mode Do not disturb period can be set
Number of Extensions Villa: 9 extensions;
Apartment: 4 extensions
Port(VTH)
Alarm Input 6
Alarm Output 1
Door Bell Yes (use any alarm input port)
Network Port 1, 10/100 Mbps Ethernet port
Performance (VTH)
Casing Material PC + ABS
General (VTH)
Appearance Color White
Power Supply 12 VDC, 1 A
PoE Standard
Power Adapter Optional
Installation Surface Mount
Certifications THERE IS
Accessory Bracket and alarm ribbon cable (included)
Product Dimensions 189.6 mm × 134.6 mm × 26.0 mm (7.50" × 5.30" × 1.00")
Operating Temperature –10 °C to +55 °C (+14 °F to +131 °F)
Operating Humidity 10%–95% (RH), non-condensing
Operating Altitude Beneath 3000 m (9842.52 ft)
Operating Environment Indoor
Power Consumption ≤ 2W (standby); ≤ 6W (working)
Gross Weightl 575 g (1.27 lb)
Storage Temperature 0 °C to +40 °C (+32 °F to +104 °F)
Storage Humidity 30%–75% (RH)
System (Networking Device)
Main Processor Embedded Processor
Port (Networking Device)
Network Port 4 × PoE ports with 10/100 Mbps Base-TX
2 uplink ports with 10/100 Mbps Base-TX
General (Networking Device)
Appearance Color Black
Power Supply Built-in power supply: 100–240 VAC
Certifications CE; FCC
Product Dimensions 194.0 mm × 108.1 mm × 35.0 mm (7.64" × 4.26" × 1.38")
Operating Temperature –10 °C to +55 °C (+14 °F to +131 °F)
Operating Humidity 10%–90% (RH), non-condensing
Power Consumption Idling: 0.5W; Full load: 36W
Gross Weight 1.11 kg (2.15 lb)
